The GE IC697CSE925 is a high-performance State Logic CPU module designed for the GE Fanuc Series 90-70 PLC platform. It is built for advanced industrial automation, complex sequencing control, and large-scale process systems, providing enhanced processing power and flexible programming capabilities.
Compared with earlier State Logic CPUs, the IC697CSE925 offers higher memory capacity and improved performance, making it suitable for data-intensive and logic-heavy applications in demanding industrial environments.
Technical Specifications
The IC697CSE925 delivers strong computing capability with flexible programming and large memory.
| Parameter | Specification |
|---|---|
| Model | IC697CSE925 |
| Product Type | PLC CPU Module |
| Series | GE Fanuc Series 90-70 |
| Processor | Intel 80486DX |
| Clock Speed | 96 MHz |
| Architecture | 32-bit floating-point CPU |
| Memory | 2 MB battery-backed RAM |
| Flash Memory | 256 KB non-volatile user memory |
| I/O Capacity | Up to 12,000 discrete I/O points |
| Analog Capacity | Up to 8,000 analog I/O points |
| Execution Speed | ~0.4 µs per Boolean instruction |
| Communication | Backplane (VME C.1) + serial support |
| Programming | State Logic / Ladder Logic / C |
| Power Requirement | 5 V DC backplane (~3.1 A) |
| Slot Requirement | Single-slot rack module |
This CPU is designed for high-speed deterministic control with advanced sequencing and large memory requirements.
Physical Dimensions & Weight
| Parameter | Value |
|---|---|
| Dimensions (L × W × H) | ≈ 263 mm × 58 mm × 28 mm |
| Weight | ≈ 0.5 kg – 1.0 kg |
Its standard single-slot design ensures compatibility with GE Series 90-70 racks such as CHS750, CHS790, and CHS791.
Recommended Related Models
IC697CSE925 is commonly used with:
- GE IC697CHS790 PLC Rack
- GE IC697PWR711 Power Supply Module
- GE IC697BEM713 Bus Transmitter Module
- GE IC697BEM731 Genius Bus Controller
- GE IC697CMM741 / CMM742 Ethernet Modules
- GE IC697RCM711 Redundancy Communication Module
These modules form a complete and scalable GE 90-70 automation system architecture.
Popular GE Series 90-70 CPU Modules
- IC697CPU771 – Entry-level CPU
- IC697CPU772 – High-performance floating-point CPU
- IC697CPU780 – Redundant hot standby CPU
- IC697CPU788 – Safety/TMR CPU
- IC697CSE784 – Standard State Logic CPU
- IC697CSE925 – High-performance State Logic CPU
These CPUs are selected based on performance, programming model, redundancy requirements, and system complexity.
