Brand:GE Fanuc PLC Item No.:GE IC697GDS701 Product Origin: USA Product Dimensions:480 mm × 420 mm × 180 mm Product Weight:15 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The GE IC697GDS701 is an industrial Operator/Engineering Workstation system module (GDS – Graphic Display System related component) used within the GE Fanuc Series 90-70 automation architecture. It is designed to support process monitoring, system visualization, engineering configuration, and operator interface functions in large-scale PLC/DCS environments.
Unlike CPU modules, the IC697GDS701 is part of the operator station / system display infrastructure, enabling users to monitor, configure, and interact with industrial processes in real time.
Technical Specifications
The IC697GDS701 is typically used in workstation-based industrial control environments.
Parameter
Specification
Model
IC697GDS701
Product Type
Operator / Engineering Station Module (GDS System)
Series
GE Fanuc Series 90-70
Function
Process visualization & system operation
CPU (workstation side)
UltraSPARC IIi (typical WP51 platform)
Memory
512 MB (expandable up to 2 GB)
Storage
80 GB HDD (expandable)
Display
21” CRT (dual display supported)
Resolution
Up to 1600 × 1280
Interface
System communication with PLC network
Keyboard Support
Operator + function keyboard system
Software
GDS (Graphics Display System)
System Role
HMI / Engineering / Maintenance station
This module is part of a higher-level human-machine interface and engineering system, not a direct I/O or CPU control module.
Physical Dimensions & Weight
Parameter
Value
Dimensions (L × W × H)
≈ 480 mm × 420 mm × 180 mm(typical workstation cabinet configuration)
Weight
≈ 8 kg – 15 kg (system dependent)
Applications
The IC697GDS701 is used in industrial control room environments, including:
Power plant control rooms
Oil & gas monitoring systems
Chemical and petrochemical plants
Manufacturing supervision systems
SCADA operator stations
Large-scale industrial process visualization
Advantages
Dedicated operator and engineering workstation system
