The GE IC641SUG716 is an Ethernet TCP/IP communication module designed for GE Fanuc Series Six PLC systems. It enables legacy PLC platforms to integrate with modern Ethernet-based networks, supporting data exchange, remote monitoring, and system-level communication with host computers and SCADA systems.
This module is widely used as a network upgrade solution, allowing older GE automation systems to maintain operational relevance without full system replacement.
Technical Specifications
| Parameter | Details |
|---|---|
| Manufacturer | General Electric (GE Fanuc) |
| Model | IC641SUG716 |
| Series | Series Six PLC |
| Module Type | Ethernet Communication Module |
| Communication Protocol | TCP/IP Ethernet |
| System Compatibility | GE Fanuc Series Six PLC systems |
| Function | PLC-to-network communication interface |
| Network Interface | Ethernet (RJ-type industrial connection) |
| Data Exchange | Real-time PLC data transmission |
| OS Compatibility | Windows NT / Windows 95 integration support |
| Installation | PLC rack-mounted module |
| Diagnostics | Communication status monitoring |
| Application Role | Legacy system networking upgrade |
The module is primarily used to provide Ethernet TCP/IP connectivity for GE PLC systems, enabling integration with modern industrial networks.
Physical Dimensions & Weight
| Parameter | Value |
|---|---|
| Dimensions (L × W × H) | 150 × 100 × 50 mm |
| Weight | ~2 kg |
Its compact form factor allows easy installation within existing PLC racks without major hardware modification.
System Role & Functional Behavior
The IC641SUG716 functions as a network communication bridge:
- Converts PLC internal data into Ethernet TCP/IP packets
- Enables remote monitoring and control via SCADA or HMI systems
- Supports data exchange between PLC and industrial networks
- Extends lifecycle of legacy Series Six systems
- Provides communication diagnostics and status feedback
- Facilitates integration with modern IT/OT infrastructure
It effectively transforms standalone PLC systems into network-connected automation nodes.
