The GE IS200AEADH1ACA is a Mark VIe system control module used as an analog signal interface board, typically associated with excitation, feedback processing, and control loop signal conditioning in industrial turbine and power generation systems.
It is designed to act as a critical analog signal processing and feedback interface, ensuring accurate conversion and transmission of control signals between the Mark VIe controller and field devices such as valves, actuators, and sensors.
Technical Specifications
| Parameter | Details |
|---|---|
| Manufacturer | General Electric (GE) |
| Model | IS200AEADH1ACA |
| Series | Mark VIe Control System |
| Module Type | Analog I/O / Feedback Interface Module |
| Function | Signal acquisition & analog output processing |
| Application Role | Turbine control feedback / excitation system |
| Channel Configuration | Multi-channel analog interface (system-dependent) |
| Signal Types | 4–20 mA / voltage analog signals |
| Communication | Mark VIe backplane communication |
| Signal Processing | Real-time analog conditioning & conversion |
| Diagnostics | Channel fault detection & status monitoring |
| Redundancy Support | System-level redundancy compatible |
| Mounting | Rack-mounted I/O module |
| Operating Temperature | -40°C to +70°C |
| Industrial Rating | Power generation / turbine control grade |
Physical Dimensions & Weight
| Parameter | Value |
|---|---|
| Dimensions (L × W × H) | 120 × 80 × 40 mm |
| Weight | ~0.8 – 1.0 kg |
The compact rack-mounted structure is optimized for dense Mark VIe control cabinets while maintaining strong electrical isolation and vibration resistance.
System Role & Functional Behavior
The IS200AEADH1ACA functions as a precision analog feedback and control interface module:
- Receives analog feedback signals from field sensors
- Processes and conditions signals for Mark VIe controller use
- Outputs analog control signals to actuators (valves, drives, regulators)
- Supports closed-loop turbine control applications
- Provides real-time diagnostics for signal integrity
- Ensures stable signal conversion in harsh industrial environments
It plays a key role in maintaining stable turbine performance and accurate process regulation.
Recommended Related Models
Within GE Mark VIe and turbine control systems, it is commonly paired with:
- IS200EMIOH1ACA Exciter Main I/O Board (control & I/O coordination)
- IS220PDIIH1A Discrete Input I/O Pack
- IS200DSPX Processor Module
- IS200TSVO Servo Control Module
- IS200TRLY Relay Output Board
Popular GE Mark VIe Modules
- IS200EISB excitation interface boards
- IS200TVIB vibration monitoring modules
- IS200JPDG power distribution boards
- IS220 series distributed I/O packs
- IS200TRPG protection and relay modules
