The GE DS200LDCCH1AHA is a Drive Control and LAN Communication Board used in GE Mark V Speedtronic systems. It combines drive control processing with network communication capability, enabling coordinated control of turbine or industrial drive systems while maintaining real-time data exchange across the control architecture.
This module is designed for high-reliability industrial environments where drive regulation, system communication, and fault monitoring must operate seamlessly together.
Technical Specifications
| Parameter | Details |
|---|---|
| Manufacturer | General Electric (GE) |
| Model | DS200LDCCH1AHA |
| Series | Mark V Speedtronic |
| Module Type | Drive Control / LAN Communication Board |
| Function | Drive control + system communication |
| Control Role | Motor/turbine drive regulation support |
| Communication | LAN / proprietary Mark V network interface |
| Data Processing | Real-time control signal handling |
| PCB Type | Multi-layer industrial control board |
| Reset Functions | Watchdog, manual, system-triggered reset |
| Diagnostics | Fault detection and system status monitoring |
| Connectors | Ribbon cables and multi-pin industrial headers |
| Mounting | Rack-mounted module |
| Operating Temperature | 0°C to +60°C |
| Environmental Rating | Industrial / power plant grade |
Physical Dimensions & Weight
| Parameter | Value |
|---|---|
| Dimensions (L × W × H) | 300 × 200 × 45 mm |
| Weight | ~1.6 – 2.4 kg |
Its rugged PCB structure supports continuous operation in vibration-prone turbine control cabinets.
System Role & Functional Behavior
The DS200LDCCH1AHA functions as a dual-role drive control and communication interface module:
- Executes drive control logic for turbine or motor systems
- Manages LAN-based communication within Mark V architecture
- Coordinates real-time data exchange between system modules
- Provides fault detection and diagnostic reporting
- Supports reset and watchdog control functions
- Ensures synchronized operation of control and communication layers
It acts as a central coordination board between control execution and network communication.
