The GE DS200QTBAG1ADC is a high-density RST (Relay Signal Terminal) termination board engineered for GE Mark V Speedtronic turbine control systems. It serves as a critical interface layer between field wiring and the internal control architecture, enabling precise signal distribution for monitoring, protection, and control functions in industrial turbine environments.
Designed for long-term reliability in high-noise and mission-critical applications, this module is widely used in power generation plants, petrochemical facilities, and heavy industrial automation systems where stable signal routing is essential for uninterrupted operation.
Technical Specifications (with Dimensions & Weight)
| Parameter | Specification |
|---|---|
| Manufacturer | General Electric (GE) |
| Model | DS200QTBAG1ADC |
| Series | Mark V Speedtronic |
| Product Type | RST Terminal / Transition Board |
| Function | Signal termination and routing interface |
| Terminal Capacity | 2 blocks × 72 signal wires each |
| Connectors | 1 × 40-pin connector (JFF), 1 × serial port |
| Communication | Serial diagnostic/configuration support |
| Operating Temperature | -20°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Origin | United States |
| Dimensions | approx. 160 × 160 × 120 mm |
| Weight | approx. 0.8 kg |
| Mounting Type | Rack-mounted control cabinet board |
This compact footprint allows dense signal integration while maintaining strong electrical isolation and stable performance under industrial stress conditions.
Recommended Related Models
- GE DS200QTBAG1ACB RST Terminal Board
- GE DS200QTBAG1A RST Base Variant
- GE DS200RTBAG3AHC Relay Terminal Board
- GE DS200DCFBG1A Power Supply Module
- GE IS200 series Mark V / Mark VI I/O modules
These modules are commonly combined to build a complete GE turbine control and signal management ecosystem.
Popular GE Mark V System Modules
- DS200 terminal and interface boards
- IS200 distributed control I/O systems
- EX2000 / EX2100 excitation controllers
- Speedtronic Mark V CPU and protection units
- Industrial relay and signal conditioning modules
