The GE DS200TCCBG1BED is an Extended Analog I/O Board developed for the GE Mark V Speedtronic turbine control system. As part of the TC2000 I/O architecture, this module serves as a central processing and signal interface unit, handling analog input/output data, system communication, and real-time control coordination.
What makes this board particularly valuable is its ability to combine signal processing, configuration flexibility, and communication bridging into a single compact module—making it a core component in turbine automation systems that demand precision and reliability.
Technical Specifications (with Dimensions & Weight)
| Parameter | Specification |
|---|---|
| Manufacturer | General Electric (GE) |
| Model | DS200TCCBG1BED |
| Series | Mark V Speedtronic |
| Product Type | Extended Analog I/O Board |
| Functional Acronym | TCCB |
| Core Function | Analog I/O processing & system interface |
| Processor | Intel 80196 microprocessor |
| Memory | Multiple PROM modules for firmware storage |
| Connectors | 2 × 50-pin (JCC, JDD) + multiple ribbon interfaces |
| Additional Interfaces | RS232, RTD input, CT/PT signal connectors |
| Jumper Configuration | 5 configurable hardware jumpers |
| Signal Types | 4–20 mA, RTD, voltage/current monitoring |
| LED Indicator | Yes (status monitoring) |
| Operating Temperature | -20°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Dimensions | approx. 160 × 160 × 120 mm |
| Weight | approx. 0.8 kg |
| Mounting Type | Rack-mounted PCB module |
Its integrated architecture allows seamless handling of multiple signal types while maintaining stable processing performance.
Recommended Related Models
- GE DS200TCCBG1B Analog I/O Board (base version)
- GE DS200TBCBG1AAA RTD Input Termination Board
- GE DS200TBCAG1AAB Analog I/O Terminal Board
- GE DS200TBQAG1ABB Thermocouple Terminal Board
- GE DS200LDCCH1ANA Drive Control & LAN Module
These modules are typically deployed together to form a complete Mark V signal acquisition and control system.
