The GE DS200TCQCG1BFE is a high-performance Analog I/O Processor Board engineered for the GE Mark V Speedtronic control platform. Acting as a critical signal processing layer, this module manages real-time analog data acquisition, conversion, and communication between field devices and the control system core.
Designed for precision and reliability, it enhances turbine control accuracy by ensuring stable handling of analog signals in demanding industrial environments. Its architecture supports seamless integration within Mark V systems, making it a dependable choice for maintaining operational continuity and system performance.
Technical Specifications (with Dimensions & Weight)
| Parameter | Specification |
|---|---|
| Manufacturer | General Electric (GE) |
| Model | DS200TCQCG1BFE |
| Series | Mark V Speedtronic |
| Product Type | Analog I/O Processor Board |
| Function | Analog signal processing & system communication |
| Processor | Embedded microprocessor with EPROM firmware |
| Signal Types | 4–20 mA, voltage inputs, mixed analog signals |
| Interface | Multi-pin connectors + ribbon cable interfaces |
| Configuration | Hardware jumpers for signal selection |
| Diagnostics | LED indicators + onboard test points |
| System Integration | Interfaces with terminal boards (TBCB / TBCA / TBQA) |
| Operating Temperature | -20°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Dimensions | approx. 160 × 160 × 100 mm (typical Mark V board size) |
| Weight | approx. 0.6–0.9 kg |
| Mounting Type | Rack-mounted PCB module |
Its optimized layout enables efficient signal processing while maintaining strong electrical isolation and stability.
Recommended Related Models
- GE DS200TCQBG1BBA Extended Analog I/O Board
- GE DS200TCCBG1BED Analog Processing Board
- GE DS200TBCBG1AAA RTD Input Termination Board
- GE DS200TBCAG1AAB Analog I/O Terminal Board
- GE DS200LDCCH1ANA Drive Control Module
These modules are commonly combined to form a complete analog signal acquisition and processing architecture in Mark V systems.
