The GE DS200TCQCG1BJF is an advanced Analog I/O Processor Board designed for the GE Mark V Speedtronic control system. Positioned at the heart of analog signal management, it ensures accurate acquisition, processing, and transmission of critical field data to the turbine control core.
With a focus on precision, responsiveness, and long-term stability, this module is engineered to meet the demanding requirements of modern and legacy turbine environments, where even minor signal deviations can impact overall system performance.
Technical Specifications (with Dimensions & Weight)
| Parameter | Specification |
|---|---|
| Manufacturer | General Electric (GE) |
| Model | DS200TCQCG1BJF |
| Series | Mark V Speedtronic |
| Product Type | Analog I/O Processor Board |
| Functional Acronym | TCQC |
| Core Function | Analog signal processing & data interface |
| Processor | Embedded microprocessor with EPROM firmware |
| Signal Support | 4–20 mA, voltage, mixed analog inputs |
| Interfaces | High-density connectors + ribbon cable ports |
| Configuration | Hardware jumpers + firmware-based setup |
| Diagnostics | LED indicators and onboard test points |
| Communication | Internal Mark V I/O communication bus |
| System Compatibility | Interfaces with TBCB, TBCA, TBQA boards |
| Operating Temperature | -20°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Dimensions | approx. 160 × 160 × 105 mm |
| Weight | approx. 0.7 – 0.95 kg |
| Mounting Type | Rack-mounted PCB module |
This board is optimized for efficient analog data handling while maintaining strong electrical isolation and signal integrity.
Recommended Related Models
- GE DS200TCQCG1BFE Analog I/O Processor Board
- GE DS200TCQAG1BHF Analog Processor Board
- GE DS200TCQBG1BBA Extended Analog I/O Board
- GE DS200TBCBG1AAA RTD Input Termination Board
- GE DS200TCCBG1BED Analog Processing Board
These modules together provide a complete analog processing and control infrastructure within the Mark V system.
