The GE DS200TCQAG1BEC is a precision-engineered Analog I/O Processor Board developed for the GE Mark V Speedtronic turbine control system. Designed to manage complex analog signal processing tasks, it serves as a critical interface between field instrumentation and the system’s control processors.
This module is built for high-speed data handling and exceptional signal accuracy, ensuring that turbine systems operate with optimal efficiency, stability, and safety under demanding industrial conditions.
Technical Specifications (with Dimensions & Weight)
| Parameter | Specification |
|---|---|
| Manufacturer | General Electric (GE) |
| Model | DS200TCQAG1BEC |
| Series | Mark V Speedtronic |
| Product Type | Analog I/O Processor Board |
| Functional Acronym | TCQA |
| Core Function | Analog signal acquisition & processing |
| Processor | Embedded microprocessor with EPROM firmware |
| Supported Signals | 4–20 mA, voltage inputs, analog feedback signals |
| Interfaces | Multi-pin connectors + ribbon cable ports |
| Configuration | Hardware jumpers + firmware configuration |
| Diagnostics | LED indicators and onboard test points |
| Communication | Internal Mark V I/O communication bus |
| System Integration | Works with TBCB, TBCA, TBQA terminal boards |
| Operating Temperature | -20°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Dimensions | approx. 160 × 160 × 100 mm |
| Weight | approx. 0.65 – 0.9 kg |
| Mounting Type | Rack-mounted PCB module |
The module’s compact yet robust design ensures efficient installation while maintaining strong resistance to electrical noise and environmental stress.
Recommended Related Models
- GE DS200TCQAG1BHF Analog I/O Processor Board
- GE DS200TCQCG1BJF Analog Processor Board
- GE DS200TCQBG1BBA Extended Analog I/O Board
- GE DS200TBCBG1AAA RTD Input Termination Board
- GE DS200TCCBG1BED Analog Processing Board
These modules are commonly used together to create a complete analog signal processing framework within Mark V systems.
