The GE IS230TDBTH2A (ordering reference: IS200TDBTH2ACD) is a PDIO (Power Distributed Input/Output) Terminal Board used in GE Mark VIe / Mark VIeS turbine control systems. It is designed to interface directly with discrete I/O packs, providing structured termination for field contact signals and ensuring safe, stable communication between field devices and the control system.
This module is engineered for high-integrity industrial signal handling, supporting redundant architectures and hazardous-location applications where reliability and fault tolerance are critical.
Technical Specifications (with Dimensions & Weight)
| Parameter | Specification |
|---|---|
| Manufacturer | General Electric (GE) |
| Model | IS230TDBTH2A / IS200TDBTH2ACD |
| Series | Mark VIe / Mark VIeS |
| Product Type | PDIO Terminal Board (Discrete I/O) |
| Function | Digital input/output signal termination |
| Compatible I/O Pack | IS220PDIOH1A / IS220PDIOH1B |
| Input Type | Dry contact / wet contact inputs |
| Input Voltage Range | 24 VDC / 48 VDC / 125 VDC systems supported |
| Channels | Multiple isolated discrete I/O groups |
| Mounting Type | DIN rail or rack-mounted panel |
| Communication | Interfaces with Mark VIe distributed control system |
| Hazardous Area Use | Supported (system dependent configuration) |
| Operating Temperature | -40°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Dimensions | approx. 160 × 160 × 120 mm |
| Weight | approx. 0.8–1.0 kg |
This board is optimized for high-density signal termination while maintaining electrical isolation and industrial-grade durability.
Recommended Related Models
- GE IS230TDBTH8A Terminal Board
- GE IS200TDBSH2A Discrete I/O Terminal Board
- GE IS220PDIOH1A Discrete I/O Pack
- GE IS220PTURH1A Turbine Control Module
- GE IS230TDBSH2ACC Signal Interface Board
These modules form a complete distributed I/O ecosystem for Mark VIe turbine control systems.
