The GE IS230TBAOH2C (ordering reference: IS200TBAOH1CCB) is an Analog Output Terminal Board used in GE Mark VIe / Mark VIeS turbine control systems. It is designed to provide a secure and structured interface between control system outputs and field devices such as actuators, valves, and drives.
This module ensures accurate analog signal distribution, strong electrical isolation, and stable output performance, making it a key element in turbine regulation, process control, and industrial automation systems where precision control is essential.
Technical Specifications (with Dimensions & Weight)
| Parameter | Specification |
|---|---|
| Manufacturer | General Electric (GE) |
| Model | IS230TBAOH2C / IS200TBAOH1CCB |
| Series | Mark VIe / Mark VIeS |
| Product Type | Analog Output Terminal Board |
| Function | Analog signal output termination & distribution |
| System Compatibility | GE Mark VIe distributed control system |
| Output Signal Types | 4–20 mA / voltage analog outputs |
| Channel Interface | Multiple isolated output channels |
| I/O Pack Compatibility | Interfaces with IS220/IS230 AO/PDIO I/O packs |
| Signal Isolation | Channel-to-channel electrical isolation |
| Configuration | Hardware jumper / system configuration via controller |
| Mounting Type | DIN rail or rack-mounted panel installation |
| Operating Temperature | -40°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Dimensions | approx. 160 × 160 × 120 mm |
| Weight | approx. 0.8 kg |
Its compact, industrial-grade design supports high-density wiring while maintaining stable analog signal performance in demanding turbine environments.
Recommended Related Models
- GE IS230TDBTH2A / IS200TDBTH2ACD PDIO Terminal Board
- GE IS230TDBSH2A Digital I/O Terminal Board
- GE IS220PAOCH1A Analog Output I/O Pack
- GE IS220PDIOH1A Discrete I/O Pack
- GE IS230TNAIH2C Analog Input Module
These modules collectively form a complete distributed I/O and signal control architecture in Mark VIe systems.
