The ABB Bailey IMQRS22 is an advanced Quad Redundant System (QRS) interface module designed for the INFI 90 distributed control system (DCS). It is engineered to support high-availability automation architectures where continuous operation, fault tolerance, and system synchronization are critical.
Within industrial control environments, the IMQRS22 plays a key role in coordinating redundant controller paths and ensuring seamless switchover between system channels. It is widely used in power generation, oil & gas, and heavy process industries, where downtime is not acceptable.
Technical Specifications
| Item | Specification |
|---|---|
| Product Type | Quad Redundant System Interface Module |
| System | ABB Bailey INFI 90 DCS |
| Function | Redundancy control and system synchronization |
| Architecture | Quad redundancy (QRS) |
| Communication | Controlway / system backplane bus |
| Interface Type | INFI 90 rack backplane |
| Power Supply | +5 V DC |
| Current Consumption | ~450–650 mA |
| Processing Role | Redundancy monitoring and failover coordination |
| Module Format | Single-slot PCB module |
| System Compatibility | INFI 90 / Symphony legacy platforms |
| Operating Temperature | 0°C to 70°C |
| Humidity | 5%–95% non-condensing |
| Protection Class | Industrial-grade control environment |
Dimensions & Weight
| Item | Value |
|---|---|
| Size (L × W × H mm) | 37 × 314 × 178 mm |
| Weight | approx. 0.3 – 0.6 kg |
