The ABB Bailey ITCTU04 is an advanced Termination Unit Module used in the INFI 90 distributed control system (DCS). It serves as a critical interface between field wiring and analog input modules, ensuring accurate signal termination, isolation, and stable data transmission across industrial control systems.
In complex process automation environments, reliable termination is essential for maintaining signal integrity and minimizing electrical noise. The ITCTU04 is designed to support high-density analog signal connections, making it widely used in power plants, oil & gas facilities, petrochemical industries, and large-scale manufacturing systems.
It is typically paired with ABB Bailey analog input modules to simplify field wiring and improve system maintainability.
Technical Specifications
| Item | Specification |
|---|---|
| Product Type | Analog Input Termination Unit |
| System | ABB Bailey INFI 90 / Net 90 DCS |
| Function | Field signal termination and interface |
| Input Channels | 16 single-ended or 8 differential channels |
| Supported Signals | Thermocouples, RTDs, voltage, current |
| Signal Interface | Field wiring terminal blocks |
| Resolution Support | Up to 16-bit system accuracy (module dependent) |
| Isolation | 2500 VRMS channel isolation |
| Compatibility | IMASI / IMRAE / IMASM analog modules |
| Communication | Passive interface (no processing logic) |
| Power Requirement | +5 V DC (via system interface) |
| Module Type | Rack-mounted termination board |
| Operating Temperature | 0°C to 60°C |
| Humidity | 5%–95% non-condensing |
| Protection Class | Industrial control environment rated |
Dimensions & Weight
| Item | Value |
|---|---|
| Size (L × W × H mm) | 178 × 51 × 203 mm |
| Weight | approx. 0.7 kg |
