The ABB Bailey NDSM01 is a versatile Digital Slave Module designed for the INFI 90 / Net 90 distributed control system (DCS). It is used to expand and manage discrete signal communication between field devices and the central control system, supporting both monitoring and control functions in industrial automation environments.
As part of ABB Bailey’s digital I/O architecture, the NDSM01 enables efficient handling of multiple digital signals such as status indications, interlocks, alarms, and control commands. It is widely used in power generation plants, oil refineries, petrochemical complexes, and large-scale manufacturing systems, where reliable digital signal processing is essential for operational safety and system coordination.
Technical Specifications
| Item | Specification |
|---|---|
| Product Type | Digital Slave Module |
| System | ABB Bailey INFI 90 / Net 90 DCS |
| Function | Digital signal expansion and distributed I/O control |
| Signal Types | Dry contact / 24 V DC digital signals |
| Channel Capacity | Multi-channel digital I/O support |
| Interface | INFI 90 proprietary system backplane |
| Input/Output Role | Combined digital input and output handling |
| Response Time | Fast industrial switching performance |
| Isolation | Electrical isolation between channels and system |
| Diagnostics | Module status and signal monitoring |
| Compatibility | ABB Bailey processors and I/O modules |
| Module Type | Rack-mounted PCB module |
| Power Supply | System backplane powered |
| Operating Temperature | 0°C to 70°C |
| Humidity | 5%–95% non-condensing |
Dimensions & Weight
| Item | Value |
|---|---|
| Size (L × W × H mm) | 102 × 127 × 178 mm |
| Weight | approx. 0.7 – 1.2 kg |
