Brand:Woodward Item No.:8200-1508 Product Origin:USA Product Dimensions:215.9 x 157.48 x 78.74 mm Product Weight:1.9 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Woodward 8200-1508 505 Compact Steam Turbine Controller is ideal for engineers requiring precise, reliable, and compact turbine control. Its advanced digital control architecture ensures accurate speed and load regulation, while the integrated diagnostics and event logging simplify maintenance and troubleshooting. The controller’s small form factor and flexible integration make it particularly suitable for constrained or portable installations, offering performance and reliability without compromise.
Technical Specifications
Specification
Details
Module Type
505 Compact Steam Turbine Controller
Control Capability
Speed, load, and temperature regulation
Communication
EtherNet/IP, Modbus TCP/RTU, Woodward Remote I/O
I/O Support
Digital and analog I/O (expandable)
Diagnostics
Event logs, alarm history, fault detection
Environmental Ratings
Vibration, shock, industrial temperature tolerant
Operating Temperature
0°C to 55°C (32°F to 131°F)
Storage Temperature
-20°C to 70°C (-4°F to 158°F)
Mounting
Panel or cabinet installation
Dimensions (H × W × D)
215.9 × 157.48 × 78.74 mm (8.5 × 6.2 × 3.1 in)
Weight
1.9 kg (4.2 lbs)
Applications
The Woodward 8200-1508 505 Compact Steam Turbine Controller is engineered for compact turbine systems where high-performance control, real-time monitoring, and operational reliability are required. Typical applications include:
Small to medium steam turbine units in industrial plants.
Skid-mounted or modular turbine systems for distributed power generation.
Auxiliary turbines in cogeneration or combined-cycle power plants.
Remote or portable turbine installations where space and accessibility are limited.
Applications requiring integrated digital control and local monitoring.
Its compact size allows integration into panels or control cabinets without compromising the quality of control and monitoring functions.
Advantages
Compact and Lightweight: Small footprint and 1.9 kg weight allow installation in confined spaces.
Real-Time Control: Optimized algorithms provide precise speed, load, and temperature regulation.
Integrated Diagnostics: Logs operational events, alarms, and faults for easy troubleshooting.
Flexible Connectivity: Supports standard Woodward I/O modules and network communication protocols.
User-Friendly Interface: Simple configuration and monitoring reduce setup time and operator training.
Technical FAQs
Which turbines can this controller operate?
Designed primarily for small to medium steam turbines, with configurable parameters for various models.
What communication protocols are supported?
EtherNet/IP, Modbus TCP/RTU, and proprietary Woodward Remote I/O.
Does it provide safety protection?
Yes, over-speed, load-limit, and emergency shutdown protections are built-in.
Can it log operational data for performance analysis?
Yes, the controller maintains event logs, fault histories, and alarm tracking.
Is it suitable for retrofitting existing turbines?
Yes, configurable I/O mapping allows integration with legacy sensors and actuators.
What is the response time for load changes?
Closed-loop control response is typically under 50 milliseconds, enabling fast turbine adjustments.
Can operational parameters be adjusted during runtime?
Yes, adjustments can be made via HMI or networked interface without halting the turbine.
What environmental conditions can it tolerate?
Industrial-grade design handles vibration, shock, and temperatures from 0°C to 55°C (32°F to 131°F).
Is remote monitoring possible?
Yes, data can be accessed via SCADA or networked control systems.
Does it support modular I/O expansion?
Yes, additional Woodward I/O modules can be integrated to extend digital and analog control points.
