Name: Woodward 8200-205 Servo Position Controller
Brand: Woodward
SKU: 9444
Availability: InStock
Rating: 5.0 (1 reviews)

Introduction

The Woodward 8200-205 Servo Position Controller is engineered for high-performance industrial applications requiring precise, repeatable, and reliable actuator control. By combining digital servo algorithms, real-time feedback, and robust industrial design, it allows engineers to achieve optimal control of turbine, engine, or process systems. Its integration with 8200 series controllers and modular I/O architecture ensures scalable and flexible deployment, while advanced diagnostics and remote monitoring reduce operational risk.

Technical Specifications

Specification	Details
Module Type	Servo Position Controller
Control Capability	Rotary and linear actuator positioning
Communication	EtherNet/IP, Modbus TCP/RTU, Woodward digital interface
Position Accuracy	±0.25% of full-scale travel
Feedback	Real-time digital position feedback
Environmental Ratings	Shock, vibration, industrial temperature tolerant
Operating Temperature	0°C to 55°C (32°F to 131°F)
Storage Temperature	-20°C to 70°C (-4°F to 158°F)
Mounting	Panel or cabinet installation
Dimensions (H × W × D)	482.6 × 310.4 × 142.7 mm (19 × 12.2 × 5.6 in)
Weight	2.35 kg (5.18 lbs)

Applications

The Woodward 8200-205 Servo Position Controller is designed for precise actuation and control of industrial turbine, engine, and process systems where high-resolution positioning is critical. Typical applications include:

Servo-driven valve actuation in steam and gas turbines.
Precise control of hydraulic and pneumatic actuators in industrial automation.
Integration into distributed control systems for power generation and process industries.
Auxiliary and backup turbine systems requiring fast, accurate position feedback.
Systems requiring digital closed-loop control with real-time monitoring and diagnostics.

The 8200-205 enables engineers to achieve high-performance positioning, improving efficiency, safety, and reliability in complex control environments.

Advantages

High-Precision Control: Maintains accurate servo positioning for fast-responding turbine or actuator applications.
Robust Integration: Compatible with 8200 series controllers and modular I/O for scalable system design.
Digital Feedback: Real-time position monitoring ensures accurate closed-loop control.
Durable Industrial Design: Rated for vibration, shock, and industrial temperature ranges.
Simplified Maintenance: Remote diagnostics, configurable alarms, and event logging reduce downtime.

Technical FAQs

Which types of actuators can it control?
Supports rotary and linear servo-driven actuators, including hydraulic and pneumatic systems.
What communication protocols are supported?
EtherNet/IP, Modbus TCP/RTU, and Woodward proprietary digital interfaces.
What is the positioning accuracy?
Typically ±0.25% of full-scale travel, enabling precise actuator movement.
Can it provide real-time position feedback?
Yes, continuous digital feedback allows closed-loop control and diagnostics.
Is it suitable for redundant or critical systems?
Yes, dual power inputs and configurable redundant channels ensure uninterrupted operation.
Can it handle rapid load changes?
Yes, closed-loop servo control responds within milliseconds for fast-actuation applications.
Does it integrate with SCADA or HMI systems?
Yes, full integration with supervisory control and local HMI is supported.
What environmental conditions can it tolerate?
Designed for industrial applications, with vibration, shock, and temperature tolerance of 0°C to 55°C (32°F to 131°F).
Is remote calibration and tuning possible?
Yes, parameters can be adjusted via network interface or connected HMI without shutting down the system.
What maintenance and diagnostic features are included?
Event logging, fault history, alarm reporting, and position trend monitoring for preventive maintenance.
