Introduction

The Allen Bradley 1606-XLSRED/A Power Supply is a small, high-performance 24V DC module designed for compact industrial applications. Its rugged construction, high efficiency, and reliable output make it ideal for tight control panels, robotics, and distributed automation networks. Engineers value its combination of space-saving design, durability, and consistent power delivery.

Technical Specifications

Specification	Details
Module Type	Power Supply Module
Input Voltage	85–264V AC
Output Voltage	24V DC
Output Current	Up to 2.5A
Efficiency	>90%
Protections	Overcurrent, short-circuit, thermal protection
Environmental Ratings	Shock, vibration, industrial temperature tolerant
Operating Temperature	-25°C to 70°C (-13°F to 158°F)
Storage Temperature	-40°C to 85°C (-40°F to 185°F)
Mounting	DIN rail or panel mountable
Dimensions (H × W × D)	124 × 32 × 102 mm (4.9 × 1.26 × 4 in)
Weight	0.29 kg (0.64 lbs)

Applications

The Allen Bradley 1606-XLSRED/A Power Supply is engineered to provide compact, reliable 24V DC power for a variety of industrial automation systems. Key applications include:

Supplying power to Allen Bradley controllers, I/O modules, and communication interfaces.
Industrial automation systems in manufacturing, process control, and material handling.
Robotics, motion control, and other precision equipment requiring reliable DC power.
Integration into machine control panels with space constraints.
Retrofit and upgrade of legacy Allen Bradley systems requiring small, high-efficiency power supplies.

This module ensures consistent power delivery in compact form, ideal for tight control panel layouts.

Advantages

Compact and Lightweight: 124 × 32 × 102 mm, 0.29 kg – fits easily into small control panels.
Reliable Power Output: Provides stable 24V DC for consistent operation of industrial devices.
High Efficiency: Reduces energy consumption and heat generation.
Industrial-Grade Durability: Resistant to vibration, shock, and industrial temperature variations.
LED Status Indicators: Quick visual feedback for operational status and fault detection.
Easy Integration: Ideal for small systems or panels with limited space.

Technical FAQs

What input voltage range does it support?
Operates on 85–264V AC input for industrial use.
What output voltage does it provide?
Regulated 24V DC output suitable for controllers and I/O modules.
Can it power multiple devices?
Yes, within its rated current capacity.
Does it include protection features?
Yes, overcurrent, short-circuit, and thermal protection are built-in.
Is it suitable for continuous operation?
Yes, designed for 24/7 operation in industrial environments.
What is the efficiency rating?
High efficiency, typically above 90%, minimizing heat and energy loss.
Does it include thermal shutdown?
Yes, automatically shuts down if overheating occurs.
Can it be DIN rail mounted?
Yes, compatible with standard DIN rail or panel mounting.
Does it maintain voltage stability under varying loads?
Yes, it ensures a stable 24V DC output even under load fluctuations.
Is maintenance required?
Minimal; periodic inspection of wiring and status LEDs is recommended.
