Name: Woodward 9905-864 Digital Steam Turbine Controller
Brand: Woodward
SKU: 9578
Availability: InStock
Rating: 5.0 (1 reviews)

Introduction

The Woodward 9905-864 Digital Steam Turbine Controller combines advanced digital control technology with a rugged, industrial-grade design. It delivers precise turbine regulation and reliable performance for industrial and power generation applications. Compact yet powerful, this controller provides operators with confidence, efficiency, and accurate control for both standalone and networked turbine systems.

Technical Specifications

Specification	Details
Module Type	Digital Steam Turbine Controller
Turbine Types Supported	Steam Turbines
Control Functions	Speed regulation, Load control, Fault protection
Communication	Ethernet, Digital Interfaces
Operating Voltage	12–24V DC
Operating Temperature	-20°C to 70°C
Protection Features	Overcurrent, Overvoltage, Fault Detection
Mounting Options	Panel or DIN rail
Dimensions (L x W x H)	263 mm x 58 mm x 28 mm
Weight	1.36 kg (3.0 lb)

Applications

The Woodward 9905-864 Digital Steam Turbine Controller is engineered for precise steam turbine regulation in industrial and power generation applications. It is ideal for turbine speed control, load management, and process automation in power plants and industrial facilities. Its robust design ensures consistent performance and reliable operation under demanding conditions.

Advantages

Precision Turbine Control: Maintains optimal steam turbine speed and load under varying conditions.
Fast and Responsive: Advanced digital algorithms ensure rapid adjustments for stable operation.
Rugged Industrial Design: Built to withstand high temperatures, vibration, and harsh environments.
Flexible Integration: Compatible with analog, digital, and PWM input signals for seamless automation.
User-Friendly Interface: Simplifies commissioning, monitoring, and control for operators.

Technical FAQs

Q: What types of turbines can the 9905-864 control?
A: Supports industrial and power plant steam turbines.
Q: How is speed accuracy maintained?
A: Uses advanced digital feedback loops and control algorithms for precise speed regulation.
Q: Can it operate in extreme environmental conditions?
A: Yes, designed for -20°C to 70°C with vibration and shock resistance.
Q: Is remote monitoring supported?
A: Yes, Ethernet and digital communication interfaces allow remote supervision.
Q: Can multiple controllers be networked together?
A: Yes, it supports multi-controller integration for coordinated turbine control.
Q: How is system protection implemented?
A: Integrated overcurrent, overvoltage, and fault detection protect both the turbine and controller.
Q: Is firmware upgradable in the field?
A: Yes, secure in-field firmware updates are supported without interrupting operation.
Q: What input signals are compatible?
A: Accepts analog, digital, and PWM inputs for flexible integration.
Q: How is calibration performed?
A: Onboard calibration routines ensure accurate turbine speed and load monitoring.
Q: What mounting options are available?
A: Supports panel and DIN rail mounting for flexible installation.
