Name: Woodward IRI1-I5E05D Ground Fault Relay
Brand: Woodward
SKU: 9633
Availability: InStock
Rating: 5.0 (1 reviews)

Introduction

The Woodward IRI1-I5E05D Ground Fault Relay provides fast, reliable, and robust protection against ground faults in industrial and marine power systems. Its compact design, precise detection, and compatibility with Woodward modules make it essential for safe and efficient operation of generators, motors, and critical electrical equipment.

Technical Specifications

Specification	Details
Module Type	Ground Fault Relay
Control Functions	Ground fault detection, Alarm/Trip output
Communication	Relay Outputs, Digital Interfaces
Operating Voltage	Control: 24–48V DC
Operating Temperature	-20°C to 70°C
Protection Features	Ground fault detection, Alarm/Trip relay
Mounting Options	Panel, DIN Rail
Dimensions (L x W x H)	260 mm x 72 mm x 138 mm
Weight	1.5 kg (3.31 lb)

Applications

The Woodward IRI1-I5E05D Ground Fault Relay is engineered to protect electrical systems from ground faults and insulation failures. It provides fast and reliable detection of leakage currents, preventing damage to generators, motors, and other critical industrial or commercial equipment. Ideal for industrial plants, marine applications, and power generation systems requiring precise fault protection.

Advantages

Rapid Fault Detection: Detects ground faults and insulation failures instantly to protect equipment.
Reliable Protection: Ensures safe operation of generators, transformers, and industrial systems.
Robust Construction: Designed for harsh environments, including vibration, temperature changes, and industrial conditions.
Seamless Integration: Compatible with Woodward control modules, ATS systems, and generator sets.
Compact Design: Space-efficient for panel or DIN rail mounting without compromising functionality.

Technical FAQs

Q: What voltage systems is the IRI1-I5E05D compatible with?
A: Supports low and medium voltage AC systems typically used in industrial and marine applications.
Q: How quickly does it detect a ground fault?
A: Detection occurs within milliseconds to prevent damage to connected equipment.
Q: Can it integrate with other Woodward control modules?
A: Yes, fully compatible with ATS controllers, generator controllers, and operator interfaces.
Q: Is it suitable for harsh industrial environments?
A: Yes, designed for -20°C to 70°C with resistance to vibration and shock.
Q: What mounting options are available?
A: Supports panel and DIN rail mounting for versatile installation.
Q: Does it provide alarm or trip outputs?
A: Yes, configurable relay outputs allow alarms or system shutdown during a fault.
Q: Can it operate in multi-unit systems?
A: Yes, multiple relays can be networked to monitor complex power distribution systems.
Q: Does it support testing or calibration?
A: Yes, the relay includes built-in testing and calibration procedures.
Q: What is the operating voltage range for the control circuit?
A: Operates on 24–48V DC for control and monitoring functions.
Q: Does it comply with industrial standards?
A: Yes, designed to meet IEC and IEEE standards for ground fault protection.
