Introduction

The Bently Nevada 3500/05-02-04-00-00-00 System Rack delivers high-performance machinery protection in a compact 12-inch format. With 7 module slots, it is perfect for installations where space is limited but precision monitoring is critical. Designed for industrial environments, this rack ensures reliable operation, supports predictive maintenance, and integrates seamlessly with the Bently Nevada 3500/05 system, safeguarding equipment and reducing unplanned downtime.

Technical Specifications

Specification	Details
Rack Size	12-inch standard
Module Slots	7
Weight	4.5 kg
Compatibility	3500/05 series modules
Mounting Type	Rack or cabinet mountable
Operating Temperature	-20°C to 70°C
LED Indicators	Module status, power, fault
Construction	Industrial-grade metal, vibration-resistant
Redundancy Support	Compatible with redundant configurations
Compliance	CE and industrial standards

Recommended Related Models

Bently Nevada 3500/22-01-01-00-00-01 Vibration Monitor Module
Bently Nevada 3500/33-01-00-00-00-01 Proximity Probe Interface
Bently Nevada 3500/05-01-02-RU-00-01 System Rack

Popular Related Models

Bently Nevada 3500/25-01-01-00-00-01 Process Monitoring Module
Bently Nevada 3500/15-01-01-00-00-01 High-Speed Shaft Monitor
Bently Nevada 3500/05-01-02-R0-00-02 System Rack

Applications

The Bently Nevada 3500/05 System Rack is engineered for compact yet high-performance machinery monitoring. Its 7-slot 12-inch design makes it ideal for:

Medium-scale turbines, compressors, and pumps
Critical rotating machinery in confined spaces
Industrial plants requiring space-efficient module integration
Remote or localized monitoring stations
Systems that demand reliable condition monitoring and predictive maintenance

Advantages

Compact Design: 12-inch width and 7 module slots provide a space-efficient solution without compromising performance.
Industrial-Grade Durability: Built to resist vibration, temperature variations, and electrical noise.
High Reliability: Supports real-time monitoring and early fault detection for critical equipment.
Easy Maintenance: Front-access modules simplify inspection, replacement, and upgrades.
Seamless Integration: Fully compatible with the 3500/05 series for flexible system configuration.

Technical FAQs

Q: How many modules can this rack accommodate?
A: Up to 7 modules.
Q: What are the physical dimensions and weight?
A: 12-inch standard width, 7 module slots; weight: 4.5 kg.
Q: Is this rack compatible with all 3500/05 series modules?
A: Yes, fully compatible with the 3500/05 monitoring modules.
Q: Can it operate in harsh industrial environments?
A: Yes, it is designed for vibration, temperature, and electrical resilience typical of industrial operations.
Q: Does it support redundant system configurations?
A: Yes, it can be integrated into redundant setups for critical operations.
Q: Are diagnostic indicators provided?
A: Yes, LED indicators show module status, power, and fault conditions.
Q: How is maintenance performed?
A: Front-access design allows easy inspection and module replacement.
Q: Can it be installed in standard control cabinets?
A: Yes, its compact 12-inch design allows flexible cabinet integration.
Q: Is future expansion possible?
A: Yes, modules can be added within the available 7-slot configuration or by connecting additional racks.
Q: What is the expected service life?
A: Typically exceeds 15 years with proper maintenance.
