The Allen Bradley 2711P-T7C22D9P PanelView Plus 7 Performance Terminal is a high-end industrial HMI (Human Machine Interface) designed for advanced machine visualization, process control, and real-time operator interaction. Built on Rockwell Automation’s modern PanelView Plus 7 platform, it delivers strong computing performance, enhanced graphics handling, and reliable communication with ControlLogix and CompactLogix PLC systems.

This model is widely used in smart manufacturing environments where fast screen response, data clarity, and network reliability are critical for maintaining production efficiency and minimizing downtime.

Technical Specifications

Category	Specification
Product Family	PanelView Plus 7 Performance
Model Number	2711P-T7C22D9P
Display Type	TFT active-matrix color LCD
Screen Size	6.5 inches
Resolution	640 × 480 (VGA)
Aspect Ratio	4:3
Touch Type	Analog resistive touchscreen
Operating System	Windows 10 IoT Core (Performance platform)
Communication	Ethernet (DLR support), USB
Input Voltage	24V DC (18–30V range)
Memory	512 MB RAM / 512 MB storage (typical platform spec)
Brightness	~300 nits (variant dependent)
Protection Rating	IP66 front panel (typical PanelView Plus 7 design)
Operating Temperature	0°C to 55°C

Physical Dimensions & Weight

Parameter	Value
Dimensions (L × W × H)	152 mm × 176 mm × 69 mm
Weight	Approx. 1.2–1.4 kg

Recommended Related Models

For scalable Rockwell automation system design, the following models are commonly paired with the 2711P-T7C22D9P:

Allen Bradley 2711P-T7C21D8S PanelView Plus 7 Standard
Allen Bradley 2711P-T10C22D9P PanelView Plus 7 Performance (larger screen)
Allen Bradley 1769-L33ER CompactLogix Controller
Allen Bradley 1756-L85E ControlLogix CPU Module
Allen Bradley 1784-SD1 Secure Digital Memory Card

These components ensure seamless HMI-to-PLC integration and stable industrial communication.

Popular Allen Bradley PanelView Models

2711P-T7C22D9P PanelView Plus 7 Performance
2711P-T7C21D8S PanelView Plus 7 Standard
2711P-T10C22D9P PanelView Plus 7 Performance (10-inch)
2711P-T6C21D8S Compact HMI Terminal
2711P-T6M5A8 PanelView Plus 6 Legacy Series

Applications

The 2711P-T7C22D9P is widely deployed in high-performance industrial automation systems where real-time visualization is essential:

Automotive manufacturing lines
High-speed packaging and sorting systems
Food and beverage processing plants
Water treatment and pumping stations
HVAC and energy management systems
Complex multi-machine production environments

Its improved processing capability makes it suitable for multi-screen, data-heavy HMI applications.

Advantages

This Performance-series HMI offers a strong combination of usability and industrial-grade reliability:

Faster processing performance for complex HMI screens
High-resolution color graphics with smooth visualization
Dual Ethernet support with Device Level Ring (DLR) capability
Secure integration with Rockwell PLC ecosystems
Rugged industrial design for continuous operation
Easy maintenance with FactoryTalk View Machine Edition

It is particularly valued in environments requiring high uptime and fast operator response.

Technical FAQs

1. What is the main function of 2711P-T7C22D9P?
It is an industrial HMI used for machine monitoring and control.

2. Which PLC systems is it compatible with?
It works with Allen Bradley CompactLogix and ControlLogix systems.

3. What software is used for configuration?
FactoryTalk View Machine Edition.

4. What operating system does it use?
Windows 10 IoT Core (Performance platform).

5. What is the screen size?
6.5-inch TFT color display.

6. Does it support Ethernet communication?
Yes, including DLR (Device Level Ring) networking.

7. What is the input voltage?
24V DC nominal (18–30V range).

8. Is it touchscreen?
Yes, resistive touchscreen interface.

9. What industries use it most?
Manufacturing, packaging, water treatment, and process automation.

10. What makes it a “Performance” model?
It has enhanced processing power, improved communication capabilities, and better handling of complex HMI applications.
