The Emerson VE5001 is an AC/DC System Power Supply Module used in DeltaV M-Series Distributed Control Systems (DCS). It provides regulated DC power to critical system components such as the controller, I/O subsystem, and communication modules.
The module is designed to ensure stable, isolated, and reliable power distribution, supporting continuous industrial process operation.
Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Emerson |
| Model | VE5001 |
| Module Type | Power Supply Module |
| System Platform | DeltaV M-Series |
| Input Voltage | 90–265 VAC, 47–63 Hz |
| Output Voltages | +12 VDC, +5 VDC, +3.3 VDC |
| Function | System power distribution for controller + I/O |
| Redundancy | Supported (system dependent) |
| Hot Swap | Supported |
| Efficiency | High efficiency design |
| Protection | Overvoltage, short-circuit protection |
| Mounting Type | DeltaV controller/carrier mounted |
| Operating Temperature | 0°C to 60°C (typical operating range) |
| Storage Temperature | -40°C to +70°C |
| Humidity | 5–95% RH non-condensing |
Physical Dimensions & Weight
| Parameter | Specification |
|---|---|
| Dimensions (L × W × H) | 43 × 125 × 185 mm |
| Weight | Approx. 0.4 kg |
Key Features
- Provides system power for DeltaV controllers and I/O modules
- AC to DC conversion with multiple output rails
- Supports redundant power configurations
- Hot-swappable design for minimal downtime
- High efficiency and low heat generation
- Integrated protection functions
- Industrial-grade reliability
