Allen Bradley 22D-D024N104 PowerFlex 40P AC Drive

Robust AC Drive for Medium-Power Industrial Motor Control

The Allen Bradley 22D-D024N104 PowerFlex 40P AC Drive delivers reliable and precise control of three-phase AC motors in industrial applications requiring medium power. Its compact design allows easy integration into control panels, providing energy-efficient operation, accurate speed and torque control, and consistent performance in demanding environments.

Perfect for industries that need flexible motor control, scalable system integration, and durable hardware.

Applications include:

• Conveyor and material handling systems
• Pumps, fans, and HVAC equipment
• Packaging and processing machinery
• Chemical, petrochemical, and oil & gas operations
• Power generation and utility automation
• Modular and distributed control panels
• Industrial automation requiring compact drive solutions

Key Advantages

• Medium-Power Capability: Supports motors up to 5 HP (3.7 kW) reliably.
• Precise Motor Control: Accurate speed, torque, and directional regulation.
• Energy Efficient Operation: Optimizes motor performance and reduces energy consumption.
• Compact Panel Integration: 260 × 130 × 180 mm footprint for small control panels.
• Industrial-Grade Design: Durable construction for long-term operation in harsh conditions.
• Flexible Networking: Compatible with EtherNet/IP and Profibus adapters.
• Easy Maintenance: Simplified setup, monitoring, and replacement reduces downtime.

Technical FAQs

1. What is the primary function of this drive?

It controls three-phase AC motors with precision for speed, torque, and direction.

2. What is the power rating?

The 22D-D024N104 is rated for 5 HP (3.7 kW) motors.

3. Can it communicate with industrial networks?

Yes, via optional EtherNet/IP or Profibus communication adapters.

4. Is it suitable for industrial environments?

Yes, it is built for continuous operation in harsh conditions.

5. Does it support variable torque applications?

Yes, suitable for both variable and constant torque operations.

6. What protection features are included?

Overload, overcurrent, and fault protection are integrated.

7. Can it be used in multi-drive setups?

Yes, it supports coordinated control of multiple drives on a network.

8. How is it configured?

Through keypad, PC software, or connected automation controller.

9. Which industries use this drive?

Manufacturing, chemical, oil & gas, utilities, HVAC, and process automation.

10. Can it handle frequent start/stop operations?

Yes, it is designed for frequent motor cycling without performance degradation.
