Introduction

The Allen Bradley 80190-100-01-R Fiber Optic Board is a high-performance communication module that enables secure, fast, and reliable data transfer in industrial automation systems. Its compact design and fiber optic technology provide immunity to electrical noise, making it ideal for modern PLC networks, robotics, and distributed I/O systems. Installation is straightforward, and the module supports multiple networked devices, ensuring seamless communication across complex automation setups.

Technical Specifications

Specification	Details
Dimensions	120 x 15 x 85 mm
Weight	0.06 kg (0.13 lb)
Connection Type	Multi-mode fiber optic
Operating Temperature	-20°C to +60°C
Mounting Type	DIN rail or panel mount
Compatible Systems	Allen Bradley PLCs with fiber optic I/O

Applications

The Allen Bradley 80190-100-01-R Fiber Optic Board is engineered for industrial automation environments that demand high-speed, reliable communication. Key applications include:

Linking distributed PLC modules across factory floors
Industrial robotics requiring fast, interference-free signal transmission
Conveyor and packaging systems with precise timing requirements
High-speed data transfer in harsh or electrically noisy environments

This board provides consistent, low-latency fiber optic communication, ensuring accurate and stable operation across your automation network.

Advantages

High-speed optical data transfer for mission-critical systems
Compact footprint allows installation in tight spaces
Immunity to electromagnetic interference enhances signal integrity
Quick installation with standardized connectors
Supports multiple networked devices without signal degradation

The 80190-100-01-R delivers reliable communication in a small, efficient package, improving automation system performance while minimizing downtime.

Technical FAQs

What type of fiber optic cable is compatible?
Supports standard multi-mode fiber optic cables used in Allen Bradley systems.
Is the board immune to electrical noise?
Yes, optical transmission ensures complete immunity to EMI and RFI.
Which Allen Bradley PLCs are supported?
Compatible with PLC models that accept fiber optic I/O modules.
What is the maximum supported transmission distance?
Up to 300 meters with multi-mode fiber optic cabling.
Does it require an external power supply?
No, the board is powered directly by the host PLC module.
Can multiple boards be connected on the same network?
Yes, multiple boards can operate simultaneously without signal loss.
Are diagnostic indicators available?
Yes, LED status indicators display connectivity and signal integrity.
Can it be installed in high-vibration environments?
Yes, the board is designed for stable operation even in industrial machinery setups.
Is hot-swapping supported?
No, the module should be powered down during installation or removal to prevent network errors.
What maintenance is required?
Minimal; regular inspection of fiber connections is recommended to maintain optimal performance.
