Allen Bradley 5069-IB16 Compact 5000 Digital Current Sinking Input Module
Allen Bradley 5069-IB16 Compact 5000 Digital Current Sinking Input Module
0.0
Points
Brand:Allen Bradley PLC Item No.:5069-IB16 Product Origin:USA Product Dimensions:144.6 x 22 x 105.4 mm Product Weight:0.175 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Allen-Bradley 5069-IB16 Compact 5000 Digital Input Module is a core component in modern industrial automation systems, enabling efficient and reliable acquisition of field-level digital signals. It is designed for high-speed communication with CompactLogix controllers through the Compact 5000 I/O platform.
Its compact design and high channel density make it ideal for scalable automation systems where space efficiency and signal reliability are critical.
Technical Specifications
Parameter
Specification
Model
5069-IB16
Product Type
Compact 5000 Digital Sinking Input Module
Input Type
24V DC sinking
Number of Inputs
16 channels
Input Current
4–7.4 mA per channel
Voltage Range
10–32V DC
Backplane System
Compact 5000 I/O
Isolation
250V basic insulation
Mounting Type
DIN rail / system backplane
Operating Temperature
0 to 60 °C
Dimensions
144.6 × 22 × 105.4 mm
Weight
0.175 kg (0.386 lb)
Diagnostics
Per-channel LED status indicators
Applications
The 5069-IB16 is widely used in industrial automation environments where reliable discrete signal acquisition is required:
Machine status monitoring in automated production lines
Sensor signal acquisition (proximity, photoelectric, limit switches)
Conveyor and material handling control systems
Packaging and assembly automation equipment
Distributed I/O architectures in CompactLogix-based systems
Its sinking input design makes it suitable for sourcing-type field devices commonly used in industrial control wiring.
Advantages
16-channel high-density input design reduces cabinet space usage
Fast response time for real-time industrial signal processing
Integrated LED indicators for each channel for quick diagnostics
Stable performance under industrial electrical noise conditions
Seamless integration with Compact 5000 I/O backplane
Supports flexible distributed or local I/O configurations
Designed for long-term reliability in continuous operation systems
Technical FAQs
1. What type of input signal does this module support?
It supports 24V DC sinking digital input signals from field devices.
2. Can it be used with proximity sensors?
Yes, it is commonly used with 2-wire and 3-wire proximity sensors.
3. Does it support fast switching applications?
Yes, it is designed for high-speed discrete signal acquisition.
4. How many input channels are available?
It provides 16 independent digital input channels.
5. Is it suitable for distributed I/O systems?
Yes, it can be used in both local and remote Compact 5000 architectures.
6. Does it provide channel-level diagnostics?
Yes, each channel includes LED status indication for diagnostics.
7. Can it operate in noisy industrial environments?
Yes, it is designed with industrial noise immunity.
8. Is it compatible with CompactLogix controllers?
Yes, it integrates directly with CompactLogix 5380 and related systems.
9. Does it require external configuration?
Yes, configuration is done through Studio 5000 environment.
10. Can it be hot-swapped in operation?
Yes, it supports module replacement depending on system configuration.
