The Bently Nevada 330103-06-15-10-12-05 is a 3300 XL 8 mm Proximity Probe Module used for non-contact measurement of shaft vibration, radial displacement, axial position, and rotor dynamics in rotating machinery.
This configuration combines a “06” compact probe body class, a 150 mm probe length option, a 1.0-meter integral cable, and a “12” connector/cable configuration variant, along with a “05” certified/approved industrial variant, making it suitable for regulated or safety-critical industrial environments.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | 330103-06-15-10-12-05 |
| Product Type | 3300 XL 8 mm Proximity Probe Module |
| Measurement Technology | Eddy Current, Non-Contact |
| Probe Diameter | 8 mm |
| Probe Case Length | 06 (compact configuration class) |
| Probe Length Option | 150 mm |
| Integral Cable Length | 1.0 m |
| Connector Type | Miniature ClickLoc™ Connector (variant 12) |
| Configuration Code | 12 |
| Thread Specification | M10 × 1 |
| Housing Material | Stainless Steel |
| Probe Tip Material | PPS (Polyphenylene Sulfide) |
| Approval Option | 05 (certified / hazardous-area suitable variant) |
| System Compatibility | Bently Nevada 3300 XL Proximitor® Systems |
Dimensions & Weight
| Item | Specification |
|---|---|
| Probe Body Length | ~60 mm (06 compact class interpretation) |
| Cable Length | 1000 mm |
| Approximate Net Weight | 0.33 kg |
| Approximate Shipping Weight | 2.05 kg |
| Package Dimensions | 280 × 180 × 80 mm |
Designed for Certified Industrial Monitoring Applications
The 330103-06-15-10-12-05 is intended for machinery systems requiring both extended probe reach (150 mm) and certified operational suitability (05 variant).
It is commonly installed in:
- Turbine bearing housings
- Compressor casings
- Large pump assemblies
- Generator shaft monitoring systems
The eddy-current sensing principle ensures stable measurement of shaft position and vibration even in harsh environments involving oil mist, temperature variation, and continuous mechanical vibration.
The stainless-steel housing improves durability, while the ClickLoc™ connector system provides secure and reliable signal transmission for continuous monitoring systems.
Recommended Related Models
| Model | Description |
|---|---|
| 330103-06-14-10-12-05 | 140 mm version |
| 330103-06-15-05-12-05 | 0.5 m cable version |
| 330103-06-15-10-02-05 | standard connector variant |
| 330103-05-15-10-12-05 | alternative body class |
| 330180-90-00 | Proximitor Sensor |
Common Bently Nevada System Components
| Model | Description |
|---|---|
| 330103 Series | 3300 XL 8 mm Proximity Probes |
| 330180 Series | Proximitor Sensors |
| 330130 Series | Extension Cable Assemblies |
| 3500/42M | Vibration Proximitor Monitor Module |
| 3500/22M | Transient Data Interface Module |
| 3500/25 | Keyphasor Module |
| 3500/15 | Power Supply Module |
