Brand:Schneider PLC Item No.:ABE7CPA412 Product Origin:France Product Dimensions:83 × 67 × 70 mm Product Weight:0.18 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Schneider ABE7CPA412 Connecting Base is part of the Modicon ABE7 Telefast range, designed to simplify thermocouple signal integration into PLC-based automation systems.
It acts as an interface between multiple field temperature sensors and Schneider PLC analog input modules, providing structured signal distribution, improved wiring organization, and integrated compensation features. Widely used in industrial process control environments, it supports reliable temperature measurement acquisition in applications where accuracy, stability, and maintenance efficiency are essential.
Technical Specifications
Parameter
Description
Model
Schneider ABE7CPA412
Product Type
Connecting base / signal interface module
Series
Modicon ABE7 (Telefast system)
Number of Channels
4 thermocouple inputs
Signal Type
Thermocouple temperature signals
PLC Interface
25-way SUB-D
Compatible Modules
BMXART0414 / BMXART0814
Mounting Type
DIN rail or panel mounted
Function
Thermocouple signal distribution with CJC support
Electrical Protection
Industrial isolation design
Dimensions
83 × 67 × 70 mm
Weight
0.18 kg
Recommended Related Models
Model
Product Name
Schneider ABE7CPA412R
Thermocouple connection base variant
Schneider BMXART0414
4-channel analog thermocouple input module
Schneider BMXART0814
8-channel analog thermocouple input module
Schneider BMXCPS2000
Modicon X80 power supply module
Popular Related Models
Model
Product Name
Schneider BMXAMI0810
Analog input module
Schneider BMXDDO3202K
Digital output module
Schneider BMXDAI1604
Digital input module
Schneider ATV320U06N4B
Variable speed drive
Applications
• Modicon M340 analog input thermocouple interface systems
Used as a connection sub-base for distributing thermocouple signals into PLC analog input modules in industrial automation systems.
• Distributed temperature monitoring in process industries
Enables structured wiring of multiple thermocouple channels for temperature acquisition in chemical, oil, and power applications.
• Industrial control cabinet signal interface standardization
Simplifies field wiring by providing a centralized connection point between sensors and PLC I/O modules.
• Machine temperature supervision systems
Supports reliable integration of temperature sensors into machine monitoring and protection systems.
• HVAC and energy management temperature acquisition systems
Used to connect and organize multiple temperature measurement points in building automation systems.
• Automation system retrofit and expansion projects
Facilitates easy integration of additional thermocouple inputs without redesigning full wiring architecture.
Key Advantages
• Dedicated thermocouple signal distribution for PLC systems
Provides structured routing of multiple temperature sensor inputs into automation controllers.
• Integrated cold-junction compensation support
Ensures improved accuracy of thermocouple measurement signals in industrial environments.
• 25-way SUB-D PLC interface connection
Enables fast and standardized connection to Modicon analog input modules.
• Simplified wiring architecture for field devices
Reduces cabinet wiring complexity and improves maintenance efficiency.
• Industrial-grade isolation and signal stability
Maintains reliable signal integrity in electrically noisy environments.
• Flexible DIN rail or panel mounting options
Supports easy installation in standard industrial control cabinets.
Technical FAQs
Q1: What is the main function of this connecting base?
A: It distributes and organizes thermocouple signals between field sensors and PLC analog input modules.
Q2: How many channels does it support?
A: It supports 4 thermocouple input channels.
Q3: Which PLC systems is it compatible with?
A: It is compatible with Modicon M340 analog input modules such as BMXART0414 and BMXART0814.
Q4: What type of connection is used to the PLC?
A: It uses a 25-way SUB-D connector interface.
Q5: Does it support cold-junction compensation?
A: Yes, it includes cold-junction compensation for thermocouple accuracy.
Q6: What type of sensors can be connected?
A: It is designed for thermocouple temperature sensors.
Q7: Can it be mounted on a DIN rail?
A: Yes, it supports 35 mm DIN rail mounting.
Q8: Is it used in industrial automation systems?
A: Yes, it is widely used in process and factory automation applications.
Q9: Does it improve wiring organization?
A: Yes, it centralizes multiple sensor connections into a structured interface.
Q10: Is it suitable for retrofit projects?
A: Yes, it is commonly used in system expansion and modernization applications.
