The GE IS420UCSCH1B Controller Module is a powerful control solution designed for the Mark VIe industrial control platform. Developed for demanding automation environments, this quad-core controller provides reliable processing capability, flexible communication performance, and stable real-time operation for critical industrial applications.
Built with a compact industrial design and advanced embedded computing architecture, the IS420UCSCH1B is engineered to manage complex control tasks in power generation, turbine automation, and large-scale process systems. Its high-speed processing capability and robust hardware platform make it an excellent choice for applications requiring continuous operation, fast data handling, and dependable system coordination.
The GE IS420UCSCH1B combines industrial-grade reliability with efficient system integration, helping operators improve equipment performance, simplify maintenance processes, and enhance overall control system availability.
Technical Specifications and Hardware Overview
The IS420UCSCH1B is a UCSC quad-core controller module designed for GE Mark VIe control systems. It features a quad-core AMD G-Series processor, ECC memory architecture, embedded communication interfaces, and support for high-reliability industrial control applications.
| Specification | Details |
|---|---|
| Manufacturer | GE (General Electric) |
| Model Number | IS420UCSCH1B |
| Product Type | Quad-Core Controller Module |
| Product Family | Mark VIe Control System |
| Controller Series | UCSC Controller |
| Processor Type | AMD G-Series Quad-Core Processor |
| Processor Speed | 1.2 GHz |
| Memory Type | DDR3 SDRAM with ECC |
| Memory Capacity | 2 GB / 4 GB configuration depending on system version |
| Operating System | QNX Neutrino RTOS |
| Communication Ports | Multiple Ethernet Interfaces |
| Mounting Method | Panel / DIN-style industrial installation |
| Cooling Method | Natural convection cooling |
| Redundancy Support | Simplex and Dual configurations |
| Application | Turbine Control, Industrial Automation, Process Control |
Dimensions and Weight
The compact mechanical design of the IS420UCSCH1B allows efficient installation inside industrial control cabinets while maintaining sufficient processing capability for advanced automation applications.
| Mechanical Parameter | Specification |
|---|---|
| Height | Approx. 168 mm |
| Width | Approx. 150 mm |
| Depth | Approx. 55 mm |
| Dimensions with Mounting | Approx. 204 × 152 × 55 mm |
| Installation Space | Compact cabinet-mounted design |
| Product Weight | Approx. 1.327 kg |
| Cooling Design | Fanless convection cooling |
The optimized form factor makes the controller suitable for modernization projects, replacement applications, and new automation system installations.
