The GE IC200MDL940B Relay Output Module is a robust industrial output solution designed for GE VersaMax PLC systems. This module provides reliable relay-based switching capability for controlling external devices such as motors, valves, contactors, indicators, and other industrial loads that require flexible voltage compatibility.
Featuring 16 individually isolated Form A relay output points, the IC200MDL940B delivers excellent electrical flexibility and dependable performance in automation environments. Its isolated relay architecture allows engineers to connect different types of field devices while maintaining system stability and reducing wiring complexity.
Designed for machine builders, system integrators, and industrial maintenance applications, the GE IC200MDL940B combines compact modular construction, convenient diagnostics, and reliable switching performance to support long-term automation system operation.
Technical Specifications and Module Characteristics
The GE IC200MDL940B is a VersaMax discrete output module designed for controlling external loads through isolated relay contacts. Each output channel operates independently, providing flexible control options for AC and DC applications.
| Specification | Details |
|---|---|
| Manufacturer | GE Fanuc |
| Model Number | IC200MDL940B |
| Product Type | Relay Output Module |
| Product Family | VersaMax |
| Output Type | Isolated Form A Relay Output |
| Number of Outputs | 16 Points |
| Output Isolation | Individual Point Isolation |
| Maximum Output Current | 2.0 A per Point |
| AC Output Range | Up to 265 VAC |
| DC Output Range | Up to 125 VDC |
| Response Time | Approx. 10 ms ON / 10 ms OFF |
| Output Protection | Relay Contact Isolation |
| Status Indicators | Individual Output LEDs |
| Mounting Method | VersaMax Modular Installation |
| Application | Industrial Load Switching and Control |
Dimensions and Weight
The IC200MDL940B uses a compact VersaMax modular design, allowing efficient installation inside control cabinets while providing multiple relay output channels.
| Mechanical Parameter | Specification |
|---|---|
| Height | Approx. 110 mm |
| Width | Approx. 66.8 mm |
| Depth | Approx. 50 mm |
| Installation Style | Modular Carrier Mount |
| Product Weight | Approx. 0.29 kg |
| Shipping Weight | Approx. 0.35 kg |
The compact size and lightweight structure make the module convenient for control panel integration, replacement projects, and automation system upgrades.
Recommended Related GE Models
For different control requirements, the following GE VersaMax modules can complement the IC200MDL940B in industrial automation systems.
| Model | Description |
|---|---|
| GE IC200MDL930 | VersaMax Relay Output Module, Alternative Relay Configuration |
| GE IC200MDL742 | VersaMax Digital Output Module |
| GE IC200MDL650 | VersaMax Digital Input Module |
| GE IC200MDL632 | VersaMax High-Density Input Module |
| GE IC200PWR002 | VersaMax Power Supply Module |
These related modules allow engineers to create flexible I/O combinations based on machine requirements, signal types, and system expansion plans.
Popular GE Automation Models
GE industrial automation products are widely selected for reliable control applications across manufacturing, energy, and process industries.
| Model | Product Category |
|---|---|
| GE IC200 Series | VersaMax Modular I/O Products |
| GE IC693 Series | Series 90-30 PLC Modules |
| GE IC697 Series | High-Performance PLC Components |
| GE RX3i Series | PAC Automation Platform |
| GE IS420 Series | Mark VIe Control Modules |
These product families provide scalable solutions for both traditional PLC applications and advanced industrial control environments.
