Brand:Schneider PLC Item No.:BCH1302M12A1C Product Origin:France Product Dimensions:Length: 147.5 mm Product Weight:7 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
Introduction to Schneider BCH1302M12A1C Servo Motor
The Schneider BCH1302M12A1C Servo Motor is engineered for industrial automation applications that require precise motion control, fast response, and dependable operation. Built within the BCH servo motor platform, it provides machine manufacturers and automation professionals with a reliable solution for accurate positioning and controlled movement.
Featuring a 20-bit encoder feedback system, 130 mm flange design, keyed shaft output, and compact mechanical construction, this servo motor delivers the performance required for modern automated machinery. It is particularly suitable for applications where repeatability, speed control, and efficient motion synchronization are critical.
For industrial users maintaining Schneider Electric motion systems, the BCH1302M12A1C provides a dependable option for equipment upgrades, replacement projects, and long-term automation support.
Technical Specifications
Parameter
Specification
Manufacturer
Schneider Electric
Model Number
BCH1302M12A1C
Product Type
Servo Motor
Series
Lexium 23 Plus BCH Series
Rated Voltage
220 V AC
Power Supply Phase
Single Phase
Feedback Type
20-bit Incremental Encoder
Holding Brake
Without Brake
Shaft Type
Keyed Shaft
Shaft Diameter
22 mm
Shaft Length
47 mm
Motor Flange Size
130 mm
Cooling Method
Natural Convection
Maximum Speed
3000 rpm
Continuous Stall Current
5.60 A
Length
147.5 mm
Weight
7.00 kg (15.43 lb)
Recommended Related Models
Model
Product Type
Schneider BCH1301M12A1C
BCH Series Servo Motor
Schneider BCH1302N12A1C
BCH Series Servo Motor
Schneider BCH1303M12A1C
High Performance Servo Motor
Schneider BCH1002O12A1C
Compact Servo Motor
Schneider LXM23 Servo Drive Series
Servo Drive System
Popular Related Models
Model
Application Category
Schneider BCH0801M12A1C
Compact Motion Servo Motor
Schneider BCH1002M12A1C
Medium Power Servo Motor
Schneider BCH1303M12A1C
Industrial Servo Motor
Schneider Lexium 23 Plus Drive
Motion Control Drive
Schneider Lexium Motion Controller
Industrial Motion Controller
Applications and Advanced Motion Control Integration
The Schneider BCH1302M12A1C Servo Motor is a precision AC servo motor designed for demanding industrial motion control applications. As part of the Schneider Electric Lexium 23 Plus BCH servo motor family, it provides accurate positioning, smooth speed regulation, and reliable torque performance for automated machinery requiring high repeatability and dynamic response.
This servo motor is widely used in packaging equipment, CNC machines, assembly systems, robotics, material handling equipment, and automated production lines where precise axis movement is essential. The combination of a 20-bit incremental encoder, keyed shaft design, and optimized electromagnetic characteristics allows the BCH1302M12A1C to deliver stable motion performance in continuous industrial operation.
The BCH1302M12A1C is suitable for machine builders, system integrators, and maintenance teams looking for a dependable replacement motor for existing Schneider motion control systems. Its compact structure and efficient design make it an effective solution for improving machine accuracy, productivity, and operational reliability.
Motion Performance Advantages and Industrial Application Benefits
High-Resolution Feedback Control
The BCH1302M12A1C integrates a 20-bit incremental encoder, enabling precise feedback control for accurate positioning, smooth acceleration, and improved motion stability in automated applications.
Reliable Lexium 23 Plus Compatibility
Designed for Schneider Electric Lexium 23 Plus servo systems, this motor provides convenient integration with compatible servo drives and motion controllers, simplifying commissioning and system maintenance.
Compact 130 mm Flange Design
The 130 mm flange structure provides a balanced combination of mechanical strength and installation flexibility, making it suitable for medium-duty industrial machinery where space efficiency is important.
Stable Torque and Speed Performance
With optimized motor characteristics and a brushless AC design, the BCH1302M12A1C delivers consistent torque output and smooth rotational performance for demanding automation tasks.
Designed for Long-Term Industrial Operation
The motor’s robust construction, natural convection cooling, and industrial-grade components support reliable operation in production environments requiring continuous performance.
Technical FAQs About Schneider BCH1302M12A1C Servo Motor
1. What type of motor is the Schneider BCH1302M12A1C?
The BCH1302M12A1C is an AC brushless servo motor designed for industrial motion control applications.
2. Which Schneider servo drive series is compatible with this motor?
The motor is designed for Schneider Electric Lexium 23 Plus servo drive systems.
3. What feedback technology does the BCH1302M12A1C use?
This servo motor uses a 20-bit incremental encoder for high-resolution position and speed feedback.
4. Does the BCH1302M12A1C include a holding brake?
No. This model is configured without a holding brake.
5. What shaft design is used on this servo motor?
The BCH1302M12A1C uses a keyed shaft design for secure mechanical coupling.
6. What applications are suitable for this servo motor?
Typical applications include CNC equipment, packaging machines, robotic systems, assembly machinery, and automated production lines.
7. How can position errors from this servo motor be diagnosed?
Engineers should check encoder feedback signals, servo drive parameters, mechanical alignment, coupling conditions, and motion controller settings.
8. What can cause servo motor vibration during operation?
Common causes include incorrect servo tuning, mechanical imbalance, excessive load, encoder problems, or improper installation.
9. How can communication faults between the motor and drive be checked?
Technicians should inspect feedback wiring, connector conditions, drive alarms, and parameter configuration.
10. What maintenance procedures are recommended for this servo motor?
Regular inspection of connectors, shaft coupling, operating temperature, vibration levels, and feedback performance helps maintain reliable operation.
