Brand:Schneider PLC Item No.:BCH1302N12A1C Product Origin:France Product Dimensions:Length: 147.5 mm Product Weight:7 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
Introduction to Schneider BCH1302N12A1C Servo Motor
The Schneider BCH1302N12A1C Servo Motor is engineered to provide accurate and efficient motion control for modern industrial automation applications. As a member of the Schneider Electric BCH servo motor family, it combines high-resolution feedback technology, compact mechanical construction, and reliable torque characteristics to meet the requirements of precision machinery.
This servo motor features a 1 kW continuous power rating, 220 V single-phase supply compatibility, keyed shaft output, and a 20-bit incremental encoder system. These features allow the BCH1302N12A1C to deliver smooth acceleration, accurate positioning, and consistent operation in demanding manufacturing environments.
For automation engineers and equipment manufacturers, the BCH1302N12A1C provides a practical motion solution for machine upgrades, replacement projects, and long-term maintenance of Schneider Electric servo control systems.
Technical Specifications
Parameter
Specification
Manufacturer
Schneider Electric
Model Number
BCH1302N12A1C
Product Type
Servo Motor
Series
Lexium 23 Plus BCH Series
Continuous Power
1 kW
Rated Supply Voltage
220 V AC
Power Supply Phase
Single Phase
Maximum Mechanical Speed
3000 rpm
Continuous Stall Current
5.60 A
Feedback Type
20-bit Incremental Encoder
Holding Brake
Without Brake
Shaft Type
Keyed Shaft
Shaft Diameter
22 mm
Shaft Length
47 mm
Flange Size
130 mm
Cooling Method
Natural Convection
Connector Type
Straight Connector
Length
147.5 mm
Weight
7.00 kg (15.43 lb)
Recommended Related Models
Model
Product Type
Schneider BCH1302M12A1C
Servo Motor
Schneider BCH1302N12A1B
Servo Motor
Schneider BCH1303N12A1C
BCH Series Servo Motor
Schneider BCH1002N12A1C
Compact Servo Motor
Schneider LXM23DU15M3X
Lexium 23 Plus Servo Drive
Popular Related Models
Model
Application Category
Schneider BCH0801N12A1C
Compact Servo Motor
Schneider BCH1002M12A1C
Medium Power Servo Motor
Schneider BCH1303M12A1C
Industrial Servo Motor
Schneider Lexium 23 Plus Drive Series
Servo Drive System
Schneider Lexium Motion Controller
Industrial Motion Control Platform
Applications and Precision Motion Control Performance
The Schneider BCH1302N12A1C Servo Motor is a high-precision AC servo motor designed for industrial automation systems requiring accurate positioning, stable speed regulation, and responsive torque control. As part of the Schneider Electric Lexium 23 Plus motion control platform, this BCH series servo motor provides reliable performance for automated machinery, production equipment, and advanced motion applications.
The BCH1302N12A1C is widely applied in packaging machines, assembly equipment, CNC systems, robotics, semiconductor-related machinery, and other automated manufacturing environments where repeatability and dynamic response are essential. Equipped with a 20-bit incremental encoder and optimized electromagnetic design, the motor delivers accurate feedback control and smooth operation during continuous industrial processes.
With its compact 130 mm flange design and keyed shaft structure, this servo motor offers convenient mechanical integration for machine builders and maintenance engineers. It is an effective replacement choice for upgrading or maintaining Schneider Electric motion control systems that require dependable servo performance.
Motion Control Advantages and Industrial Reliability Features
High-Resolution Encoder Feedback
The BCH1302N12A1C integrates a 20-bit incremental encoder, allowing the servo drive system to achieve precise position feedback, improved motion accuracy, and stable control performance.
Optimized Lexium 23 Plus Compatibility
Designed for Schneider Electric Lexium 23 Plus servo drive systems, this motor provides excellent compatibility with existing Schneider motion architectures, simplifying installation, commissioning, and replacement processes.
Efficient 1 kW Servo Output
The motor provides a continuous power rating of 1 kW, making it suitable for medium-duty automation applications requiring balanced torque output and precise movement control.
Compact Mechanical Structure
The 130 mm flange size and straight connector configuration allow flexible installation in machine environments where space optimization and reliable mechanical mounting are important.
Stable Industrial Operation
The brushless AC servo design, natural convection cooling, and robust construction help support long-term operation in industrial environments with continuous motion requirements.
Technical FAQs About Schneider BCH1302N12A1C Servo Motor
1. What type of motor is the Schneider BCH1302N12A1C?
The BCH1302N12A1C is an AC brushless servo motor designed for industrial motion control applications.
2. Which Schneider motion systems are compatible with this servo motor?
This servo motor is designed for Schneider Electric Lexium 23 Plus servo drive systems.
3. What feedback device is used in the BCH1302N12A1C?
The motor uses a 20-bit incremental encoder for position and speed feedback control.
4. What is the rated operating voltage of this servo motor?
The BCH1302N12A1C operates with a rated supply voltage of 220 V AC.
5. Does this servo motor include a holding brake?
No. The BCH1302N12A1C configuration is supplied without a holding brake.
6. What are common applications for this servo motor?
Typical applications include packaging machinery, CNC equipment, robotic systems, assembly lines, and automated production equipment.
7. How can encoder feedback faults be diagnosed?
Technicians should check encoder wiring, connector conditions, servo drive alarms, feedback parameters, and motor rotation feedback signals.
8. What causes servo motor vibration during operation?
Common causes include incorrect servo tuning, mechanical imbalance, coupling problems, excessive load, or feedback signal issues.
9. What should be checked if the motor does not rotate correctly?
Engineers should inspect drive configuration, motor parameters, power connections, encoder feedback, and mechanical installation.
10. How can the BCH1302N12A1C maintain long service life?
Regular inspection of wiring, mounting conditions, operating temperature, vibration levels, and drive parameters helps maintain reliable performance.
