Brand:Schneider PLC Item No.:BCH1303N12A1C Product Origin:France Product Dimensions:Length: 167.5 mm Product Weight:7.5 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
Introduction to Schneider BCH1303N12A1C Servo Motor
The Schneider BCH1303N12A1C Servo Motor is engineered for industrial applications where precision, speed control, and reliable operation are essential. Built on Schneider Electric’s BCH servo motor platform, it provides automation engineers with a dependable motion solution for advanced manufacturing equipment.
Featuring a 1.5 kW continuous power rating, 220 V AC single-phase operation, 20-bit incremental encoder feedback, and a keyed shaft output, this servo motor delivers the accuracy and dynamic response required by modern automation systems.
The BCH1303N12A1C is particularly suitable for applications that require smooth acceleration, precise positioning, and consistent performance over long production cycles. Its compact design and Schneider Electric system compatibility make it a valuable component for machine upgrades, replacement installations, and industrial motion projects.
Technical Specifications
Parameter
Specification
Manufacturer
Schneider Electric
Model Number
BCH1303N12A1C
Product Type
Servo Motor
Series
Lexium 23 Plus BCH Series
Continuous Power
1.5 kW
Rated Supply Voltage
220 V AC
Power Supply Phase
Single Phase
Maximum Mechanical Speed
3000 rpm
Continuous Stall Current
8.30 A
Feedback Type
20-bit Incremental Encoder
Holding Brake
Without Brake
Oil Seal
Without Oil Seal
Shaft Type
Keyed Shaft
Shaft Diameter
22 mm
Shaft Length
47 mm
Flange Size
130 mm
Cooling Method
Natural Convection
Connector Type
Straight Connector
Protection Rating
IP40
Length
167.5 mm
Weight
7.50 kg (16.53 lb)
Recommended Related Models
Model
Product Type
Schneider BCH1302N12A1C
Servo Motor
Schneider BCH1303M12A1C
Servo Motor
Schneider BCH1303N32A1C
Servo Motor with Oil Seal Configuration
Schneider BCH1304N12A1C
High Performance Servo Motor
Schneider LXM23DU30M3X
Lexium Servo Drive
Popular Related Models
Model
Application Category
Schneider BCH0801N12A1C
Compact Servo Motor
Schneider BCH1002N12A1C
Medium Power Servo Motor
Schneider BCH1302M12A1C
Industrial Servo Motor
Schneider Lexium 23 Plus Servo Drive
Motion Control Drive
Schneider Lexium Motion Controller
Industrial Automation Controller
Applications and Industrial Motion Automation Solutions
The Schneider BCH1303N12A1C Servo Motor is a high-performance AC servo motor designed for precision motion control applications in modern industrial automation systems. As part of the Schneider Electric Lexium 23 Plus BCH series, this servo motor delivers accurate positioning, responsive speed control, and reliable torque output for demanding manufacturing environments.
The BCH1303N12A1C is commonly applied in packaging machinery, CNC equipment, robotic systems, semiconductor production equipment, assembly lines, and automated material handling systems. Its combination of a 1.5 kW continuous power rating, 20-bit incremental encoder feedback, and 130 mm flange design allows it to achieve stable motion performance in applications requiring repeatability and fast response.
With a compact mechanical structure and reliable servo characteristics, this model provides an effective solution for machine builders and maintenance engineers who need to upgrade, replace, or maintain Schneider Electric motion control systems. The BCH1303N12A1C helps improve machine accuracy, production efficiency, and long-term operational stability.
Performance Advantages and Precision Motion Capabilities
High-Resolution Encoder Feedback
The BCH1303N12A1C integrates a 20-bit incremental encoder, enabling precise position detection and accurate feedback control. This high-resolution feedback improves motion repeatability and allows servo drives to respond quickly to changes in load conditions.
Powerful 1.5 kW Servo Performance
With a continuous power output of 1.5 kW and a continuous stall current of 8.3 A, this servo motor provides excellent torque capability for medium-duty industrial machinery and automated production systems.
Lexium 23 Plus System Compatibility
Designed for Schneider Electric Lexium 23 Plus servo drive platforms, the BCH1303N12A1C enables smooth integration into existing motion control architectures and simplifies commissioning procedures.
Compact 130 mm Flange Design
The 130 mm mounting flange provides a practical balance between installation flexibility and mechanical strength, making the motor suitable for various industrial machine structures.
Reliable Industrial Construction
The keyed shaft design, natural convection cooling, and robust servo motor construction support stable operation in continuous automation environments.
