The HIMA F60 AO 8 01 Analog Output Module is a high-performance I/O component developed for HIMatrix F60 safety automation systems. It enables reliable transmission of analog control signals from the safety controller to external process equipment, supporting accurate regulation and efficient automation performance.
Designed for demanding industrial environments, the module combines flexible signal configuration, dependable diagnostics, and safety-oriented operation. With eight analog output channels and support for common industrial signal standards, the F60 AO 8 01 provides an effective solution for facilities requiring precise control, high availability, and long-term system reliability.
Technical Specifications
| Specification | Details |
|---|
| Manufacturer | HIMA |
| Model | F60 AO 8 01 |
| Module Type | Analog Output Module |
| System Platform | HIMatrix F60 |
| Number of Outputs | 8 Analog Outputs |
| Output Signal | 0–10 V / 0–20 mA / 4–20 mA |
| Application | Safety Automation and Process Control |
| Safety Level | SIL 3 Compatible |
| Function | Analog Signal Generation and Actuator Control |
| Configuration Tool | HIMA SILworX / Engineering Software |
| Installation Type | HIMatrix F60 Rack Mounting |
| Communication Interface | Internal F60 I/O Bus |
| Dimensions | Approx. 120 × 30 × 130 mm |
| Weight | Approx. 0.25 kg |
Recommended Companion Models
| Model | Product Name |
|---|
| F60 AI 8 01 | HIMA HIMatrix F60 8-Channel Analog Input Module |
| F60 CPU 03 | HIMA HIMatrix F60 Central Processor Module |
| F60 DI 32 01 | HIMA HIMatrix F60 32-Channel Digital Input Module |
| F60 DO 8 01 | HIMA HIMatrix F60 Relay Output Module |
Frequently Selected Alternatives
| Model | Product Name |
|---|
| F3 AIO 8/4 01 | HIMA HIMatrix Analog Input/Output Module |
| F60 AI 8 01 | HIMA HIMatrix F60 Analog Input Module |
| F60 DIO 24/16 01 | HIMA HIMatrix F60 Digital Input/Output Module |
| X-AO 16 01 | HIMA HIMax 16-Channel Analog Output Module |
Technical FAQs
1. What is the primary function of the HIMA F60 AO 8 01?
The HIMA F60 AO 8 01 is an analog output module designed to provide controlled analog signals from HIMatrix F60 safety systems to external field devices.
2. How many analog output channels does the module provide?
The module provides eight independent analog output channels for connecting compatible industrial actuators and control devices.
3. What signal types are supported by the F60 AO 8 01?
The module supports voltage and current output signals, including 0–10 V and 0/4–20 mA configurations.
4. Which HIMA systems are compatible with this module?
The module is designed for the modular HIMA HIMatrix F60 safety controller system.
5. What applications commonly use the F60 AO 8 01?
Typical applications include actuator control, valve positioning, process regulation, and safety-related analog signal output functions.
6. Is the F60 AO 8 01 suitable for safety applications?
Yes, the module is designed for safety-related HIMatrix F60 applications and supports SIL 3 safety architectures.
7. How does the module improve process control accuracy?
The module provides stable analog signal generation, allowing precise control of connected field devices and improving overall system performance.
8. Can the output channels be configured individually?
Yes, the module supports channel configuration for different voltage or current output requirements through system engineering tools.
9. What types of field devices can be connected to the module?
Compatible devices include control valves, actuators, drives, and other industrial equipment requiring analog command signals.
10. How does an analog output module differ from a digital output module?
An analog output module provides continuously variable control signals, while a digital output module provides discrete switching signals such as ON/OFF commands.
