Introduction

The Bently Nevada 3500/25 126648-02 Isolated Key Phase I/O Module is a critical component for high-fidelity machinery monitoring systems. Built to deliver precise phase reference and speed data, it enhances the accuracy of vibration diagnostics and protective functions. Its isolated input architecture ensures stable signal acquisition even in electrically noisy environments, making it a trusted choice for mission-critical rotating equipment. For facilities where uptime, accuracy, and system integrity matter, this module offers a proven and dependable solution.

Technical Specifications

Parameter	Description
Product Type	Isolated Key Phase I/O Module
System Compatibility	Bently Nevada 3500 Series
Input Type	Key Phase / Speed (Isolated)
Supported Sensors	Proximity probes, magnetic pickups
Mounting	3500 Rack Slot
Operating Environment	Industrial continuous-duty applications
Dimensions	241.3 x 24.4 x 103.1 mm
Weight	0.46 kg

Recommended Related Models

Bently Nevada 3500/22M Transient Data Interface
Bently Nevada 3500/40M Proximitor Monitor
Bently Nevada 3500/42M Vibration Monitor
Bently Nevada 3500/50M Tachometer Module

Popular Related Models

Bently Nevada 3500/15 Power Supply Module
Bently Nevada 3500/32M Relay Module
Bently Nevada 3500/33 Control Module
Bently Nevada 3500/05 System Rack

Applications

The 3500/25 Isolated Key Phase I/O Module is purpose-built for precision phase reference and speed measurement in rotating machinery protection systems. It is widely deployed in:

Turbine and generator keyphasor monitoring
Compressor and pump shaft phase reference applications
Overspeed detection and phase tracking systems
Machinery diagnostics within critical industrial assets
Power generation, oil & gas, petrochemical, and heavy industry environments

Advantages

Designed for reliability in demanding installations, this module delivers both performance and operational confidence:

Isolated input design minimizes electrical noise and signal interference
High accuracy phase reference improves vibration analysis quality
Seamless integration within the Bently Nevada 3500 monitoring platform
Robust industrial-grade construction for continuous operation
Simplifies system architecture by combining key phase and speed functions

Technical FAQs

What is the primary function of the 3500/25 module?
It provides isolated key phase and speed input signals for machinery protection and condition monitoring systems.
Is the input electrically isolated?
Yes, the module features galvanic isolation to protect against ground loops and signal distortion.
Which sensors are compatible with this module?
It supports proximity probes and magnetic pickup sensors commonly used for keyphasor applications.
Can it be used for overspeed monitoring?
Yes, the module supports accurate speed measurement suitable for overspeed detection systems.
Is this module hot-swappable?
When used in a properly configured 3500 rack, module replacement can be performed with minimal system disruption.
Does it support redundant configurations?
Yes, it can be implemented in redundant system architectures for high-availability installations.
How does isolation benefit system performance?
Isolation reduces electrical noise, improving signal integrity and measurement reliability.
Is configuration software required?
Configuration is handled through the 3500 system software environment.
What industries typically use this module?
Power generation, oil & gas, refining, mining, and large-scale manufacturing.
Is the module suitable for continuous operation?
Absolutely—it is designed for 24/7 industrial monitoring applications.
