Introduction
The Siemens 6AG4010-5DB02-0XK5 belongs to the SIMATIC IPC3000 SMART V2 industrial PC family. Its 19-inch, 4U rack-mount architecture provides a practical platform for machine visualization, supervisory applications, production monitoring, industrial data processing, and automation-system integration.
The IPC3000 SMART platform combines Gigabit Ethernet, serial communication, display interfaces, USB connectivity, and expansion capability in a conventional industrial PC architecture. Siemens documentation specifies a 509 × 481 × 177 mm length × width × height envelope and an unpackaged weight of approximately 13.3 kg, with packaging bringing the specified weight to approximately 17 kg.
Technical Specifications
| Specification | Details |
|---|
| Manufacturer | Siemens |
| Article Number | 6AG4010-5DB02-0XK5 |
| Product Family | SIMATIC IPC3000 SMART V2 |
| Product Type | Industrial PC |
| Installation | 19-inch rack mount |
| Chassis Height | 4U |
| Processor | Exact article-specific configuration not independently verified |
| Memory | Exact article-specific configuration not independently verified |
| Storage | Exact article-specific configuration not independently verified |
| Operating System | Exact article-specific configuration not independently verified |
| Ethernet | Gigabit Ethernet |
| Serial Communication | RS-232 / RS-422 / RS-485, configuration dependent |
| USB | Multiple USB interfaces |
| Display Interfaces | VGA, DVI-D |
| Expansion | PCI/PCIe |
| Power Supply | 100–240 V AC |
| Protection Rating | IP20 |
| Dimensions (L × W × H) | 509 × 481 × 177 mm |
| Weight | Approx. 13.3 ± 1.0 kg, unpackaged |
| Packaged Weight | Approx. 17.0 ± 1.0 kg |
Recommended Companion Models
| Model | Product Name |
|---|
| 6AG4010-5BD33-0XF5 | SIMATIC IPC3000 SMART V2 Industrial PC |
| 6AG4010-5BD33-0XX5 | SIMATIC IPC3000 SMART V2 Industrial PC |
| 6AG4010-5BB32-0FX5 | SIMATIC IPC3000 SMART V2 Industrial PC |
| 6AG4010-5BB32-0XX5 | SIMATIC IPC3000 SMART V2 Industrial PC |
Frequently Selected Alternatives
| Model | Product Name |
|---|
| 6AG4010-5BA32-0FX5 | SIMATIC IPC3000 SMART V2 Industrial PC |
| 6AG4010-5BA30-0FX5 | SIMATIC IPC3000 SMART V2 Industrial PC |
| 6AG4010-5AB32-0FX5 | SIMATIC IPC3000 SMART V2 Industrial PC |
| 6AG4010-5AB30-0FX5 | SIMATIC IPC3000 SMART V2 Industrial PC |
Technical FAQs
What is the Siemens 6AG4010-5DB02-0XK5?
The 6AG4010-5DB02-0XK5 is a SIMATIC IPC3000 SMART V2 industrial PC intended for industrial automation, visualization, supervisory, and data-processing applications.
What type of installation is supported?
The SIMATIC IPC3000 SMART platform uses a 19-inch, 4U rack-mount design and can be installed in suitable industrial cabinets or rack systems.
What networking capability is available?
The IPC3000 SMART platform provides Gigabit Ethernet connectivity for communication with industrial networks, automation devices, and supervisory systems.
Can serial automation equipment be connected?
Yes. The platform supports serial communication, including configurable RS-232/RS-422/RS-485 functionality on applicable configurations.
What display interfaces are available?
The IPC3000 SMART platform provides VGA and DVI-D display interfaces for compatible industrial or standard monitors.
Does the 6AG4010-5DB02-0XK5 support USB peripherals?
Yes. Multiple USB interfaces are provided for compatible peripherals, service equipment, and removable storage.
Can additional expansion cards be installed?
Yes. The IPC3000 SMART platform provides PCI/PCIe expansion capability, subject to the specific hardware configuration and available slots.
What power supply does the platform use?
The IPC3000 SMART platform supports 100 to 240 V AC input, with the exact electrical configuration subject to the installed power supply.
What is the physical size of the IPC3000 SMART?
The Siemens documentation specifies 481 × 177 × 509 mm in width × height × depth. Expressed as length × width × height, this is approximately 509 × 481 × 177 mm.
What is the weight of the IPC3000 SMART?
The Siemens documentation specifies approximately 13.3 ± 1.0 kg for the unpackaged unit, while a packaged weight of approximately 17.0 ± 1.0 kg is also specified.
