Introduction
The Siemens 6AG4010-5DD00-0XD5 belongs to the SIMATIC IPC3000 SMART industrial PC family. Its 19-inch, 4U rack-mount architecture is intended for machine visualization, supervisory applications, production monitoring, industrial data processing, and automation-system integration.
The exact processor, memory, storage, and operating-system configuration for this specific article number could not be independently confirmed from the available article-specific records. These values are therefore not inferred from another IPC3000 variant. The physical platform specifications are supported by Siemens documentation, which gives dimensions of 509 × 481 × 177 mm in length × width × height and an unpackaged weight of approximately 13.3 kg.
Technical Specifications
| Specification | Details |
|---|
| Manufacturer | Siemens |
| Article Number | 6AG4010-5DD00-0XD5 |
| Product Family | SIMATIC IPC3000 SMART V2 |
| Product Type | Industrial PC |
| Installation | 19-inch rack mount |
| Chassis Height | 4U |
| Processor | Exact article-specific configuration not independently verified |
| Memory | Exact article-specific configuration not independently verified |
| Storage | Exact article-specific configuration not independently verified |
| Operating System | Exact article-specific configuration not independently verified |
| Ethernet | Gigabit Ethernet |
| Serial Communication | Supported; exact configuration to be verified |
| USB | Multiple USB interfaces |
| Display Interfaces | VGA, DVI-D, configuration dependent |
| Expansion | PCI/PCIe |
| Power Supply | 100–240 V AC platform specification |
| Protection Rating | IP20 |
| Dimensions (L × W × H) | 509 × 481 × 177 mm |
| Weight | Approx. 13.3 ± 1.0 kg, unpackaged |
| Packaged Weight | Approx. 17.0 ± 1.0 kg |
Recommended Companion Models
| Model | Product Name |
|---|
| 6AG4010-5DB02-0XK5 | SIMATIC IPC3000 SMART V2 Industrial PC |
| 6AG4010-5BD33-0XF5 | SIMATIC IPC3000 SMART V2 Industrial PC |
| 6AG4010-5BD33-0XX5 | SIMATIC IPC3000 SMART V2 Industrial PC |
| 6AG4010-5BB32-0FX5 | SIMATIC IPC3000 SMART V2 Industrial PC |
Frequently Selected Alternatives
| Model | Product Name |
|---|
| 6AG4010-5BA32-0FX5 | SIMATIC IPC3000 SMART V2 Industrial PC |
| 6AG4010-5BA30-0FX5 | SIMATIC IPC3000 SMART V2 Industrial PC |
| 6AG4010-5AB32-0FX5 | SIMATIC IPC3000 SMART V2 Industrial PC |
| 6AG4010-5AB30-0FX5 | SIMATIC IPC3000 SMART V2 Industrial PC |
Technical FAQs
What is the Siemens 6AG4010-5DD00-0XD5?
The 6AG4010-5DD00-0XD5 is an industrial PC configuration associated with the SIMATIC IPC3000 SMART platform for automation, visualization, supervisory, and data-processing applications.
What type of installation is supported?
The IPC3000 SMART platform uses a 19-inch, 4U rack-mount design and supports installation in suitable industrial cabinets and rack systems.
What networking capability is available?
The IPC3000 SMART platform provides Gigabit Ethernet connectivity for communication with industrial networks, automation equipment, and supervisory systems.
Can serial automation equipment be connected?
Yes. The IPC3000 SMART platform supports serial communication for compatible controllers, instruments, drives, and legacy automation equipment.
What display interfaces are available?
The IPC3000 SMART platform supports VGA and DVI-D display connectivity on applicable configurations.
Does the system support USB peripherals?
Yes. Multiple USB interfaces are available for compatible peripherals, maintenance equipment, and removable storage.
Can expansion cards be installed?
Yes. The IPC3000 SMART platform provides PCI/PCIe expansion capability, subject to the particular hardware configuration and available slots.
What power input is supported?
The documented IPC3000 SMART platform supports 100 to 240 V AC input, with the exact power-supply configuration depending on the installed unit.
What are the physical dimensions of the IPC3000 SMART?
The Siemens documentation specifies 481 × 177 × 509 mm in width × height × depth. Expressed as length × width × height, the dimensions are approximately 509 × 481 × 177 mm.
What is the weight of the IPC3000 SMART?
The documented platform has an unpackaged weight of approximately 13.3 ± 1.0 kg. The packaged weight is approximately 17.0 ± 1.0 kg.
