Introduction
The Siemens 6AG4010-6AB30-0XX5 SIMATIC IPC3000 SMART V3 is a 19-inch 4U industrial PC designed for automation visualization, supervisory control, machine monitoring, and industrial data processing. Its Intel Pentium G4400 processing platform, DDR4 memory architecture, internal 1 TB-class storage, dual Gigabit Ethernet, and broad peripheral connectivity provide a practical foundation for industrial software and production applications.
The chassis supports standard rack installation while retaining a comprehensive set of industrial interfaces, including configurable serial ports, USB, VGA, DisplayPort, PS/2, and Ethernet. It is therefore well suited to both new automation installations and replacement or modernization projects.
Technical Specifications
| Specification | Details |
|---|
| Manufacturer | Siemens |
| Article Number | 6AG4010-6AB30-0XX5 |
| Product Family | SIMATIC IPC3000 SMART V3 |
| Product Type | Industrial PC |
| Form Factor | 19-inch rack, 4U |
| Processor | Intel Pentium G4400 |
| CPU | 2 cores / 2 threads, 3.30 GHz, 3 MB cache |
| Memory | DDR4 SDRAM, 2 slots; up to 2 × 16 GB supported |
| Installed Memory | Configuration-dependent |
| Storage | 1 TB-class internal SATA storage |
| Drive Bay | 1 × 3.5-inch; 3 × 5.25-inch drive bays |
| Ethernet | 2 × RJ45, 10/100/1000 Mbps |
| Serial Interfaces | 2 × rear COM, RS-232/RS-422/RS-485 configurable |
| USB | 2 × front USB 2.0; 4 × rear USB 3.0, plus internal USB connections |
| Display | 1 × VGA; 1 × DisplayPort |
| Keyboard / Mouse | 2 × PS/2 |
| Audio | High-definition audio, microphone / line-in / line-out |
| Expansion | 3 × PCI; PCIe expansion slots |
| Power Supply | 350 W, 100–240 V AC |
| Operating System | Configuration-dependent; Windows 10 Professional 64-bit listed for this configuration |
| Dimensions (L × W × H) | Approx. 509 × 481 × 176 mm |
| Weight | Approx. 13.3–17 kg, configuration-dependent |
| Installation | 19-inch rack / industrial cabinet |
Recommended Companion Models
| Model | Product Name |
|---|
| 6AG4010-6AB30-0AX5 | SIMATIC IPC3000 SMART V3 Industrial PC |
| 6AG4010-6AB30-0DX5 | SIMATIC IPC3000 SMART V3 Industrial PC |
| 6AG4010-6AB30-0FX5 | SIMATIC IPC3000 SMART V3 Industrial PC |
| 6AG4010-6AB25-0XX5 | SIMATIC IPC3000 SMART V3 Industrial PC |
Frequently Selected Alternatives
| Model | Product Name |
|---|
| 6AG4010-6BB30-0XX5 | SIMATIC IPC3000 SMART V3 Industrial PC |
| 6AG4010-6BB20-0XX5 | SIMATIC IPC3000 SMART V3 Industrial PC |
| 6AG4010-6AB20-0XX5 | SIMATIC IPC3000 SMART V3 Industrial PC |
| 6AG4010-6AB25-0XX5 | SIMATIC IPC3000 SMART V3 Industrial PC |
Technical FAQs
1. What is Siemens 6AG4010-6AB30-0XX5?
It is a SIMATIC IPC3000 SMART V3 industrial PC designed for industrial automation, HMI, SCADA, visualization, monitoring, and supervisory computing applications.
2. What processor is used in the 6AG4010-6AB30-0XX5?
The documented configuration uses an Intel Pentium G4400, a dual-core processor operating at 3.30 GHz with 3 MB cache. The processor is suitable for general-purpose industrial visualization and automation workloads.
3. How much memory does this IPC support?
The IPC3000 SMART V3 platform uses DDR4 SDRAM and provides two memory slots, with platform documentation specifying support for up to 2 × 16 GB. The exact factory-installed capacity should be confirmed against the individual unit configuration.
4. What storage is provided?
The identified 6AB30-0XX5 configuration is associated with 1 TB internal storage. The IPC3000 SMART V3 chassis provides a 3.5-inch drive position for internal storage.
5. What Ethernet interfaces are available?
The IPC3000 SMART V3 platform provides two RJ45 Ethernet interfaces, supporting 10/100/1000 Mbps operation, with features such as Wake-on-LAN and remote boot support.
6. What serial and USB interfaces are provided?
The platform provides two rear-panel COM ports supporting RS-232, RS-422, and RS-485 modes. It also provides front and rear USB connectivity, including two front USB 2.0 ports and four rear USB 3.0 ports.
7. What display interfaces are available?
The platform provides one VGA interface and one DisplayPort interface for connecting local displays. It also includes PS/2 keyboard and mouse connectivity.
8. What operating system is installed?
Available product listings associate this configuration with Windows 10 Professional 64-bit Chinese, but operating-system configuration can depend on the original order. The installed OS should therefore be verified on the individual unit.
9. What are the dimensions of the 6AG4010-6AB30-0XX5?
The documented IPC3000 SMART V3 chassis measures approximately 509 × 481 × 176 mm (L × W × H), corresponding to 481 × 176 × 509 mm in W × H × D orientation. Without the rack handles, the chassis depth is approximately 466 mm.
10. What is the weight of the industrial PC?
The IPC3000 SMART V3 platform has a configuration-dependent weight of approximately 13.3–17 kg. The actual weight depends on the installed processor, memory, storage, expansion hardware, and other options.
