Introduction
The Siemens 6AG4010-6AB31-0FX5 is part of the SIMATIC IPC3000 SMART V3 family of rack-mounted industrial computers. Its 19-inch 4U chassis provides a practical combination of industrial communication, display connectivity, USB interfaces, and PCI/PCIe expansion for automation and visualization systems.
The publicly available information for this exact article number does not provide sufficient confirmation of its processor, installed memory, storage, and operating-system configuration. These options should therefore be checked against the product nameplate or order documentation before final system selection.
Technical Specifications
| Specification | Details |
|---|
| Manufacturer | Siemens |
| Article Number | 6AG4010-6AB31-0FX5 |
| Product Family | SIMATIC IPC3000 SMART V3 |
| Product Type | Industrial PC |
| Form Factor | 19-inch rack, 4U |
| Processor | Article-specific configuration to be confirmed |
| Memory | Article-specific configuration to be confirmed |
| Storage | Article-specific configuration to be confirmed |
| Operating System | Article-specific configuration to be confirmed |
| Ethernet | 2 × RJ45, 10/100/1000 Mbps |
| Serial Interfaces | 2 × COM, RS-232/RS-422/RS-485 |
| USB | 2 × front USB 2.0, 4 × rear USB 3.0, additional internal USB |
| Display | 1 × VGA, 1 × DisplayPort |
| Keyboard/Mouse | 2 × PS/2 |
| Audio | Audio input/output and microphone |
| Expansion | PCI and PCIe slots |
| Power Supply | 350 W, 100–240 VAC |
| Protection Rating | IP20 |
| Dimensions | 509 × 481 × 176 mm (L × W × H) |
| Dimensions Without Handles | Approx. 466 × 430 × 176 mm (L × W × H) |
| Weight | Approx. 14 kg, configuration-dependent |
Recommended Companion Models
| Model | Product Name |
|---|
| 6AG4010-6AB31-0DX5 | SIMATIC IPC3000 SMART V3 Industrial PC |
| 6AG4010-6AB30-0XX5 | SIMATIC IPC3000 SMART V3 Industrial PC |
| 6AG4010-6AB25-0XX5 | SIMATIC IPC3000 SMART V3 Industrial PC |
| 6AG4010-6AB20-0XX5 | SIMATIC IPC3000 SMART V3 Industrial PC |
Frequently Selected Alternatives
| Model | Product Name |
|---|
| 6AG4010-6AB30-0DX5 | SIMATIC IPC3000 SMART V3 Industrial PC |
| 6AG4010-6AB25-0DX5 | SIMATIC IPC3000 SMART V3 Industrial PC |
| 6AG4010-6AB21-0FX5 | SIMATIC IPC3000 SMART V3 Industrial PC |
| 6AG4010-6AB23-1DX5 | SIMATIC IPC3000 SMART V3 Industrial PC |
Technical FAQs
1. What is the Siemens 6AG4010-6AB31-0FX5?
The 6AG4010-6AB31-0FX5 is a SIMATIC IPC3000 SMART V3 industrial PC intended for industrial automation, visualization, monitoring, and data-processing applications.
2. What is the form factor of this industrial PC?
It uses a 19-inch rack-mount chassis with a 4U installation height, making it suitable for standard industrial cabinets and equipment racks.
3. How many Ethernet interfaces are provided?
The IPC3000 SMART V3 platform provides two RJ45 Gigabit Ethernet interfaces supporting 10/100/1000 Mbps communication.
4. Which serial communication standards are supported?
Two COM interfaces are available, with support for RS-232, RS-422, and RS-485 communication modes.
5. Which display outputs are available?
The platform provides VGA and DisplayPort outputs for connecting industrial monitors or other compatible displays.
6. What USB connectivity is available?
The standard platform provides two front USB 2.0 ports and four rear USB 3.0 ports, with additional internal USB connectivity.
7. Can the 6AG4010-6AB31-0FX5 accept expansion cards?
Yes. The IPC3000 SMART V3 chassis supports PCI and PCIe expansion, allowing additional communication, acquisition, motion, or other industrial interface cards to be installed.
8. What is the power supply rating?
The platform uses a 350 W power supply with a 100–240 VAC input range.
9. What are the dimensions of the 6AG4010-6AB31-0FX5?
The applicable IPC3000 SMART V3 chassis is approximately 509 × 481 × 176 mm (L × W × H) with rack handles. Without the handles, the chassis is approximately 466 × 430 × 176 mm.
10. What is the weight of the 6AG4010-6AB31-0FX5?
The exact article-specific net weight is configuration-dependent. A typical IPC3000 SMART V3 chassis is approximately 14 kg, with the final installed weight depending on the processor, storage, expansion cards, and other factory options.
