The Schneider Electric 140CPS42400 is a high-performance power supply module designed to provide 24V DC power for Modicon M340 and Modicon M580 PLC systems. This advanced power supply module delivers an impressive 20A (480W) of power, making it ideal for large-scale automation and complex industrial control systems. With its reliable performance, the 140CPS42400 is essential for powering a wide range of industrial applications, from manufacturing and robotics to process control and energy management.

The 140CPS42400 is equipped with built-in protection features such as overcurrent protection, overvoltage protection, and short-circuit protection to ensure the stability and safety of the connected system. Designed with efficiency in mind, the module offers an efficiency rating of ≥ 93%, which helps reduce energy consumption and optimize operational costs.

This module is built to integrate seamlessly with Modicon M340 and Modicon M580 PLCs, providing continuous, stable, and highly efficient 24V DC power for the most demanding industrial applications.

Technical Specifications

Specification	Details
Model	140CPS42400
Module Type	Power Supply Module
Input Voltage Range	85-264 VAC, 47-63 Hz
Output Voltage	24 VDC
Output Current	20 A maximum (480W)
Power Consumption	480W (maximum)
Efficiency	≥ 93%
Operating Temperature Range	0°C to 60°C (32°F to 140°F)
Storage Temperature Range	-40°C to 85°C (-40°F to 185°F)
Dimensions (L x W x H)	6.3 x 4.0 x 7.0 inches (160 x 100 x 180 mm)
Weight	1.5 lbs (0.7 kg)
Protection Features	Overvoltage, overcurrent, and short-circuit protection
Environmental Protection	IP20 (protected against solid objects larger than 12mm)

Recommended Related Models

Schneider Electric 140CPS12400 – A smaller power supply module providing 24V DC power with 480W output, ideal for Modicon M340 and Modicon M580 setups.
Schneider Electric 140CPS11500 – A mid-range power supply module with a 600W output, designed for higher power requirements in larger automation systems.
Schneider Electric 140DPS12100 – A high-output power supply with 1200W of power, suitable for large and complex industrial control systems.
Schneider Electric 140CRA31200 – A Modicon M340 processor module, designed for compatibility with power supply models like the 140CPS42400 for large automation setups.

Popular Schneider Electric Models

Modicon M340 PLC – A modular PLC system offering flexible, scalable control for industrial automation. The 140CPS42400 provides reliable power for larger M340 configurations.
Modicon M580 ePAC – A high-performance Ethernet-based PLC used in advanced process automation and critical control applications, often powered by high-output modules like the 140CPS42400.
Schneider Electric 140CPS11400 – A mid-range power supply module providing 400W of output for smaller applications in Modicon PLC systems.
Schneider Electric 140CPS12400 – A 24V DC power supply module offering 480W output, perfect for use with Modicon M340 systems.

Applications

The 140CPS42400 is designed for applications where consistent, stable power is required to support high-demand industrial automation and process control systems. Some typical applications include:

Industrial Automation: Powering robotic systems, automated manufacturing lines, production plants, and material handling systems in various industries.
Process Control: Supplying reliable power to process control systems in industries such as oil & gas, chemical production, food and beverage, and pharmaceutical manufacturing.
Energy Management: Ensuring reliable power delivery for smart grids, energy distribution networks, and power generation systems in industrial settings.
Transportation Systems: Supporting automation and control systems for rail, aviation, and logistics applications to ensure smooth operations in the transportation sector.
Building Automation: Powering HVAC, lighting, security, and fire safety systems in commercial and industrial buildings, optimizing energy efficiency and operational reliability.

Advantages

High Power Output: With 480W and 20A output, the 140CPS42400 is perfect for high-power industrial systems, ensuring smooth operation even under demanding conditions.
Energy Efficiency: Operating with an efficiency of ≥ 93%, this power supply minimizes energy loss, helping to lower operational costs and improve system performance.
Built-in Protection: Features like overvoltage, overcurrent, and short-circuit protection ensure the safety of both the power supply and connected devices.
Compact and Durable: Despite its high power output, the compact design (160 x 100 x 180 mm) allows it to fit easily in space-constrained environments, while its IP20 protection rating ensures it performs well in typical industrial settings.
Global Compatibility: With an input voltage range of 85-264 VAC, the 140CPS42400 is suitable for use in industrial systems worldwide, adapting to varying voltage conditions.
Wide Operating Temperature Range: The module is capable of operating in temperatures between 0°C to 60°C (32°F to 140°F), making it adaptable to a variety of industrial environments.
Continuous 24V DC Power: This module provides reliable, stable 24V DC power for uninterrupted operation in critical control and automation systems.
Versatile Integration: The 140CPS42400 can be used in both small and large-scale systems, making it suitable for a wide range of industrial applications.
Cost-Effective: High efficiency and robust protection features help to minimize maintenance and replacement costs, providing a cost-effective solution for powering large automation systems.
Scalable Solution: The 140CPS42400 offers the flexibility to scale with your system's needs, ensuring reliable power for growing automation systems.

Technical FAQs

What is the output voltage of the 140CPS42400?
The 140CPS42400 provides 24V DC output, ideal for powering Modicon M340 and Modicon M580 PLC systems.
What is the maximum output current of the 140CPS42400?
The module delivers up to 20A with a maximum output of 480W.
What is the efficiency rating of the 140CPS42400?
The 140CPS42400 operates with an efficiency of ≥ 93%, which helps reduce energy consumption and improve overall system performance.
What protection features are included with the 140CPS42400?
The module comes with overvoltage, overcurrent, and short-circuit protection to safeguard the power supply and connected devices.
What is the input voltage range for the 140CPS42400?
The module supports an input voltage range of 85-264 VAC, making it suitable for use in various global environments.
What is the temperature range for the 140CPS42400?
The module operates effectively within a temperature range of 0°C to 60°C (32°F to 140°F), suitable for most industrial settings.
Can the 140CPS42400 be used for larger industrial systems?
Yes, the 140CPS42400 is designed for high-power systems, providing stable power for large-scale industrial applications.
What is the environmental protection rating of the 140CPS42400?
The module has an IP20 protection rating, protecting it from dust and solid objects greater than 12mm in size.
Is the 140CPS42400 easy to integrate into existing systems?
Yes, the 140CPS42400 is designed for seamless integration with Modicon M340 and Modicon M580 PLC systems, ensuring easy installation and reliable operation.
Is the 140CPS42400 suitable for international use?
