ABB CI501-PNIO 1SAP220600R0001-4

The ABB CI501-PNIO Communication Interface Module is a high-performance solution designed to enhance communication in industrial automation systems. Supporting PROFINET and Ethernet protocols, the CI501-PNIO ensures fast, secure, and reliable data exchange between programmable logic controllers (PLCs), field devices, and control systems. This versatile communication module is ideal for industries that require seamless integration of automation devices, real-time data processing, and continuous system monitoring.

With its support for PROFINET (a widely used industrial Ethernet protocol) and Ethernet communication, the CI501-PNIO allows for high-speed data transfer, real-time communication, and better scalability in complex automation systems. Whether you are working in factory automation, process control, or building automation, this module offers a reliable foundation for all communication needs, improving overall system performance and reducing downtime.

Technical Specifications

Parameter	Details
Model	CI501-PNIO
Type	Communication Interface Module
Supported Protocols	PROFINET, Ethernet
Data Transmission Speed	100 Mbps (Ethernet), 100 Mbps (PROFINET)
Communication Ports	1 x Ethernet (PROFINET), 1 x Ethernet
Power Supply	24V DC
Dimensions	180mm x 140mm x 45mm
Weight	0.65 kg (1.43 lbs)
Operating Temperature	-20°C to +60°C
Mounting	DIN Rail, Panel Mount
Protection Class	IP20
Indicators	LED indicators for status and diagnostics
Certifications	CE, UL, IEC, RoHS
Current Consumption	250mA
Operating Voltage Range	19.2V DC to 30V DC
