ABB CINT-01C Communication Interface Module for Integrated Network Communication – Seamless Data Exchange for Industrial Control Systems

Applications

The CINT-01C Communication Interface Module is designed to optimize the performance of various industrial applications, such as:

• Industrial Automation Networks: Seamlessly connecting controllers, sensors, actuators, and other devices for real-time data exchange and system synchronization.

• Process Control: Facilitating communication between process controllers, field devices, and SCADA systems for improved accuracy and efficiency.

• Energy Monitoring: Enabling real-time monitoring of energy consumption by connecting power meters and other control devices to a centralized system.

• Machine-to-Machine (M2M) Communication: Allowing multiple machines on a production line to communicate, synchronizing operations and improving overall efficiency.

• Building Automation: Integrating HVAC, lighting, and security systems into one centralized network for improved management and energy savings.

Advantages

• Multi-Protocol Compatibility: The CINT-01C supports both Ethernet/IP and Modbus TCP, making it suitable for a wide range of industrial communication needs.

• High-Speed Data Transfer: With communication speeds of up to 100 Mbps, the CINT-01C enables rapid and efficient data transmission, ensuring real-time communication in complex systems.

• Compact and Efficient Design: The module’s small footprint (165 x 75 x 38 mm) ensures that it can be installed in space-constrained environments without compromising performance.

• Low Power Consumption: The CINT-01C has a low current draw of just 90 mA at 24V DC, reducing energy usage and operational costs.

• Real-Time Diagnostics: Equipped with LED status indicators, the module provides immediate feedback on operational status, allowing for quick troubleshooting and minimizing downtime.

• Flexible Mounting: The module is easily DIN rail mountable, which simplifies installation and maintenance in industrial environments.

• Wide Temperature Range: The CINT-01C is designed to operate in harsh environments with temperatures ranging from -20°C to 70°C, making it suitable for a variety of industrial settings.

Technical FAQs

1. What communication protocols are supported by the CINT-01C?

   • The CINT-01C supports Ethernet/IP and Modbus TCP protocols, enabling seamless integration with a wide range of industrial devices.

2. What is the power supply requirement for the CINT-01C?

   • The module requires a 24V DC power supply and draws a current of 90 mA.

3. What is the operating temperature range for the CINT-01C?

   • The CINT-01C operates in temperatures between -20°C and 70°C and can be stored in temperatures ranging from -40°C to 85°C.

4. How is the CINT-01C mounted?

   • The CINT-01C is designed for DIN rail mounting, which simplifies installation in industrial control panels.

5. What is the maximum communication speed of the CINT-01C?

   • The CINT-01C supports communication speeds of up to 100 Mbps, enabling high-speed data transfer for real-time communication.

6. Does the CINT-01C have diagnostic features?

   • Yes, the module includes LED indicators that provide real-time status updates, allowing for quick identification of any communication issues.

7. How much does the CINT-01C weigh?

   • The CINT-01C weighs 0.4 kg (0.88 lbs), making it lightweight and easy to install.

8. Can the CINT-01C be used outdoors?

   • The module is designed for industrial environments and should be installed in a protected, indoor area, as it is not rated for direct outdoor exposure.

9. What is the physical size of the CINT-01C?

   • The CINT-01C has compact dimensions of 6.5 x 3.0 x 1.5 in (165 x 75 x 38 mm), making it suitable for installations with limited space.

10. Can the CINT-01C be used to communicate with multiple devices?

    • Yes, the CINT-01C can be used to establish communication between multiple devices in an industrial network, enabling efficient data exchange across various systems.
