The Bently Nevada 3500/61 133924-01 TC Isolation External Terminal Block provides isolated thermocouple connections for critical machinery monitoring systems. Designed for integration with 3500 series modules, it ensures accurate and interference-free signal acquisition while supporting redundant and fail-safe configurations. Compact, durable, and reliable, this module is essential for maintaining the integrity of temperature measurement signals in industrial applications.

Technical Specifications

Parameter	Details
Manufacturer	Bently Nevada
Model	3500/61 133924-01
Product Type	TC Isolation External Terminal Block
Dimensions	241.3 × 24.4 × 241.8 mm
Weight	0.91 kg
Compatibility	Bently Nevada 3500 System Modules & Racks
Environment	Industrial / Machinery Monitoring

Recommended Related Models

Bently Nevada 3500/05 System Rack – 14-slot 19-inch monitoring rack
Bently Nevada 3500/22 – System Power Supply Module
Bently Nevada 3500/23E – Transient Data Interface Module

Popular Related Models

Bently Nevada 330104-01-05-50-02-00 – 8 mm Proximity Probe
Bently Nevada 330101-00-20-05-02-00 – 8 mm Proximity Probe
Bently Nevada 3500/92 – Display and Alarm Module

Applications

The Bently Nevada 3500/61 TC Isolation External Terminal Block is designed to provide isolated thermocouple signal connections in industrial machinery monitoring systems. Typical applications include:

Isolating thermocouple signals to prevent ground loops and signal interference
Integrating with Bently Nevada 3500 series monitoring systems
Supporting condition-based maintenance and fault diagnostics
Facilitating modular wiring for critical industrial machinery
Protecting sensitive measurement signals in harsh industrial environments

Advantages

Industrial-grade construction for durability in harsh conditions
Provides isolated thermocouple connections to prevent signal interference
Seamless integration with Bently Nevada 3500 monitoring systems
Supports redundant and fail-safe system architectures
Modular design simplifies wiring and installation
Compact and reliable for long-term operation
Enhances signal integrity and machinery diagnostics

Technical FAQs

What is the primary function of this module?
It isolates thermocouple signals and provides external terminal connections.
What are the physical dimensions?
241.3 × 24.4 × 241.8 mm.
What is the weight?
0.91 kg.
Is it suitable for industrial environments?
Yes, designed for rugged machinery monitoring applications.
Can it be used in redundant monitoring systems?
Yes, supports fail-safe and redundant configurations.
Is it compatible with Bently Nevada 3500 modules?
Yes, fully compatible with the 3500 series.
Does it provide signal isolation?
Yes, for thermocouple connections to prevent ground loops.
Does it simplify integration into system racks?
Yes, modular design allows easy installation in 3500/05 racks.
Is it suitable for continuous operation?
Yes, engineered for long-term industrial use.
Can it enhance measurement accuracy?
Yes, by preventing signal interference and maintaining thermocouple integrity.
