ABB SDCS-COM-81 Fast Optical DDCS Communication Module for DCS800 Drive Systems and AC800M Controllers
ABB SDCS-COM-81 Fast Optical DDCS Communication Module for DCS800 Drive Systems and AC800M Controllers
0.0
Points
Brand:ABB PLC Item No.:ABB SDCS-COM-81 Product Origin:Sweden Product Dimensions:225 × 150 × 50 mm Product Weight:0.50 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The ABB SDCS-COM-81 Communication Module is a high-speed optical communication board developed to support data exchange in ABB industrial drive and automation systems. Designed as part of the SDCS drive control architecture, this module enables reliable communication between ABB drive controllers and higher-level automation platforms such as distributed control systems.
The module utilizes DDCS (Drive Digital Communication System) optical communication technology to provide fast and deterministic data transfer between drive units and supervisory controllers. This capability allows engineers and operators to monitor system performance, configure drive parameters, and integrate drive equipment into centralized automation systems.
Engineered for demanding industrial environments, the SDCS-COM-81 offers stable communication, strong resistance to electrical interference, and seamless integration with ABB drive platforms such as DCS800 and AC800M control systems. Its design ensures consistent performance in applications where real-time data exchange and precise control are essential.
Technical Specifications
Parameter
Specification
Model
SDCS-COM-81
Product ID
3ADT220134R0001
Product Type
Fast Optical DDCS Communication Module
Manufacturer
ABB
Communication Technology
Optical DDCS
Data Transfer Rate
Up to 10 Mbaud
Compatible Systems
ABB DCS800 drive systems, AC800M controllers
Power Supply
Powered via drive backplane
Operating Voltage
24 V DC (typical)
Power Consumption
Approx. 4.5–5 W
Operating Temperature
0 °C to +55 °C
Storage Temperature
−40 °C to +85 °C
Installation
Plug-in communication board
Dimensions (L × W × H)
225 × 150 × 50 mm
Weight
0.50 kg
Recommended Related Models
Model
Module Type
SDCS-COM-82
Optical Communication Module
SDCS-AMC-DC-2
Drive Control Board Module
SDCS-POW-1
Drive Power Supply Module
SDCS-IOB-3
I/O Interface Module
SDCS-FEX-2
Field Excitation Control Module
Popular ABB Models
Model
Module Type
PM783F
Processor Module
PM901F
Controller CPU Module
RMIO-01C
Motor Interface Module
RDCU-12C
Drive Control Unit
RUSB-02
Communication Adapter Module
Applications
The ABB SDCS-COM-81 Fast Optical Communication Module is designed for industrial environments that require reliable communication between drive systems and automation platforms.
Typical applications include:
Industrial DC drive systems
Steel and rolling mill production lines
Mining and heavy material handling systems
Paper and pulp manufacturing equipment
Cement and building material plants
Conveyor and mechanical drive systems
Large distributed automation systems
By enabling high-speed optical communication between drive controllers and central control systems, the module helps ensure precise coordination and stable system performance across industrial processes.
Advantages
High-Speed Optical Communication
The module supports 10 Mbaud optical DDCS communication, enabling fast and reliable data exchange between drives and control systems.
Strong Immunity to Electrical Interference
Fiber-optic communication minimizes the impact of electromagnetic noise, making it ideal for heavy industrial environments.
Reliable Integration with ABB Drive Platforms
Designed specifically for ABB drive architectures, ensuring smooth compatibility with DCS drive systems and AC800M controllers.
Compact and Efficient Design
The module’s plug-in board format allows quick installation and easy integration within drive control racks.
Enhanced Monitoring and Diagnostics
Supports real-time system monitoring and parameter configuration for improved maintenance and operational control.
Industrial-Grade Reliability
Built with durable electronic components designed for continuous operation in demanding industrial applications.
Technical FAQs
1. What is the ABB SDCS-COM-81 module used for?
It provides high-speed optical communication between ABB drive systems and automation controllers.
2. Which communication protocol does the module use?
It uses ABB’s DDCS optical communication protocol for fast data exchange.
3. What is the communication speed of the module?
The module supports data transmission speeds of up to 10 Mbaud.
4. Which systems commonly use this module?
It is commonly used in ABB DCS800 drive systems and AC800M control platforms.
5. What is the typical operating voltage?
The module typically operates with 24 V DC supplied through the host drive system.
6. What are the dimensions of the module?
The module measures 225 × 150 × 50 mm.
7. What is the approximate weight?
The module weighs approximately 0.50 kg.
8. Where is the module installed?
It is installed as a plug-in board within the drive control rack or communication slot.
9. What environments is the module designed for?
Industrial environments such as steel plants, mining operations, and large automation facilities.
10. Why is optical communication beneficial in drive systems?
Fiber-optic communication provides faster data transfer and improved immunity to electrical interference, ensuring stable system performance.
