Introduction

The GE IS200SSCAH2A Terminal Board delivers reliable connectivity for serial communication and I/O signal routing in industrial control and turbine protection systems. Its compact design, modular architecture, and industrial-grade durability ensure stable operation, easy integration, and simplified maintenance in demanding environments.

Technical Specifications

Parameter	Specification
Dimensions (L x W x H)	160 × 110 × 30 mm
Weight	0.454 kg (1.00 lb)
Mounting	DIN rail or panel mount
Terminal Type	Screw/clamp
Wire Gauge Support	Up to 2.5 mm²
Operating Temperature	-20°C to 70°C
Humidity	5% – 95% non-condensing
Channel Isolation	Yes
Compliance	IEC 61508, ISO 9001

Applications

The GE IS200SSCAH2A Terminal Board is designed to provide efficient and reliable connectivity for serial communication and I/O interfaces in industrial turbine protection and automation systems. Its typical applications include:

Integration with GE turbine protection modules
Serial communication between control panels and monitoring systems
SCADA and DCS data acquisition networks
Industrial control panels requiring organized and secure wiring
Environments demanding high reliability, noise isolation, and compact design

Its compact 160 × 110 × 30 mm form factor ensures easy panel integration while supporting robust connectivity.

Advantages

Reliable Connectivity: Ensures stable communication and signal routing across connected modules.
Compact Design: Saves valuable panel space without compromising functionality.
Industrial-Grade Durability: Resists vibration, temperature fluctuations, and humidity.
Flexible Integration: Fully compatible with GE turbine protection systems and selected third-party modules.
Noise Isolation: Electrically isolates channels to reduce cross-talk and signal degradation.
Maintenance-Friendly: Clearly labeled terminals simplify wiring, troubleshooting, and replacement.

Technical FAQs

Q: Which communication types does this terminal board support?
A: Supports serial I/O connections compatible with GE turbine protection modules.
Q: Can it handle high-vibration environments?
A: Yes, designed for industrial-grade stability in vibration-prone systems.
Q: What is the operating temperature range?
A: Continuous operation from -20°C to 70°C.
Q: How are wires connected to the board?
A: Standard screw or clamp terminals securely accommodate multiple wire gauges.
Q: Can multiple boards be linked for larger systems?
A: Yes, modular design allows for series connection to expand terminal capacity.
Q: Does it provide diagnostic features?
A: Yes, it allows verification of connections during maintenance or system testing.
Q: How does it enhance system safety?
A: Electrically isolates channels and ensures reliable signal routing to prevent single-point failures.
Q: Is it compatible with RTD terminal blocks and other modules?
A: Yes, designed for seamless integration with GE IS200 series modules.
Q: Does it require a separate power supply?
A: No, it functions passively, routing signals from module to module.
Q: How easy is maintenance or replacement?
A: Modular and labeled design allows quick replacement without disrupting connected circuits.
