The Emerson SE4052S1T2B6 is a DeltaV S-Series 32-channel High Side Discrete Output Module designed for reliable switching and control of field devices in complex industrial automation environments. It delivers stable 24 VDC digital output signals to actuators, solenoids, relays, indicators, and other discrete control elements within a Distributed Control System (DCS).
Engineered for high-channel-density applications, this module combines robust output performance with integrated mass termination architecture, enabling efficient wiring and simplified cabinet design. It is widely used in large-scale process plants where multiple discrete outputs must be controlled with precision, speed, and diagnostic visibility.
With strong electrical protection and DeltaV-native integration, the SE4052S1T2B6 is a dependable solution for modern industrial control systems requiring scalable digital output capacity.
Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Emerson |
| Model | SE4052S1T2B6 |
| Product Type | High Side Discrete Output Module |
| Platform | DeltaV S-Series Traditional I/O |
| Output Type | Digital / Discrete Output |
| Channels | 32 Channels |
| Output Voltage | 24 VDC |
| Output Configuration | High-side switching |
| Terminal Type | 40-pin Mass I/O Terminal Block |
| Mass Connection | 4 × 8-channel DO connection boards |
| Load Type | Solenoids, relays, indicators, actuators |
| Output Isolation | Channel-to-system isolation |
| Diagnostic Function | Channel and module-level diagnostics |
| Switching Type | Electronic high-side driver |
| Response Time | Fast switching performance |
| Redundancy | System-dependent (architecture-based) |
| LocalBus Power | 12 VDC |
| Power Consumption | Industrial low-power design |
| Operating Temperature | -40°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5%–95% non-condensing |
| EMC Protection | Industrial EMI/RFI immunity |
| Shock Resistance | Industrial standard rated |
| Vibration Resistance | Industrial standard rated |
| Protection Rating | IP20 |
| Installation Type | DeltaV carrier-mounted module |
| Dimensions (H × W × D) | Approx. 130 mm × 42 mm × 107 mm |
| Weight | Approx. 0.5–0.9 kg |
Recommended Related Models
For complete DeltaV discrete control and I/O system design, SE4052S1T2B6 is commonly used with:
| Model | Function |
|---|---|
| SE4003S8B1 | Standard Digital Output Module |
| SE4003S7B1 | Digital Input Module |
| SE4051S2T2B5 | Simplex Digital Input Module |
| SE4035S2B1 | Redundant Analog Output Module |
| SE4033S2B1 | Redundant Analog Input Module |
| SE4005S2B4 | Analog Output Module |
| SE4003S2B6 | High-Density Analog Input Module |
| SE4006P2 | Serial Interface Module |
| SE4050E0C0 | 8-Wide I/O Carrier |
| DeltaV PK Controller | Compact Control System Controller |
These modules work together to form a complete, scalable automation architecture.
Popular Emerson DeltaV Discrete Output Modules
Within Emerson’s DeltaV ecosystem, SE4052S1T2B6 belongs to the high-density output family:
- SE4052S1T2B6 32-Channel High Side Discrete Output Module
- SE4002S1T2B5 32-Channel DO Module (Mass Terminal Variant)
- SE4002S1T2B6 High-Density DO Module (Alternative Mass I/O Design)
- SE4003S8B1 Standard Discrete Output Module
- SE4003S7B1 Discrete Input Module
- SE4003S2B1 Analog Input Module
- SE4005S2B4 Analog Output Module
- SE4033S2B1 Redundant Analog Input Module
- SE4035S2B1 Redundant Analog Output Module
These modules provide flexible and scalable I/O solutions for modern process plants.
