The Allen-Bradley 22B-D6P0N104 is a PowerFlex 40 series AC drive module designed for dependable variable speed control of 3-phase industrial motors up to 2.2 kW (3 HP). It delivers consistent V/Hz scalar control with optional sensorless vector performance, making it suitable for conveyors, pumps, fans, compressors, and general OEM machinery where stable torque and simple commissioning are essential.
Operating in the 480V AC industrial voltage class, this drive is widely used in factory automation systems due to its balance of compact size, robust electrical design, and straightforward integration. Its built-in keypad interface and RS-485 communication support allow easy setup in both standalone equipment and PLC-controlled systems.
According to Rockwell Automation, the model is officially End of Life (discontinued as of June 30, 2025), with a recommended upgrade path to the PowerFlex 525 series (25B-D6P0N104) for new installations and modernization projects.
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Series | PowerFlex 40 |
| Product Type | AC Drive Module |
| Input Voltage | 380–480V AC |
| Input Phase | 3-phase |
| Output Voltage | 0–460V AC (3-phase output) |
| Output Current | 6.0 A |
| Output Power | 2.2 kW (3 HP) |
| Control Method | V/Hz scalar control (sensorless vector capable) |
| Communication | RS-485 (DSI) |
| User Interface | Integrated keypad with LED display |
| Brake Function | Built-in brake IGBT |
| Protection Features | Overload, overvoltage, short-circuit protection |
| Mounting Type | Panel mount (Frame B) |
| Enclosure Rating | IP20 (open type) |
| Frequency Range | 50–60 Hz |
The drive is engineered for smooth torque delivery and stable motor response under varying industrial load conditions, ensuring consistent operation in continuous-duty applications.
Dimensions & Weight
| Item | Value |
|---|---|
| Dimensions (H × W × D) | 190 × 160 × 279 mm |
| Weight | ~1.9–2.2 kg |
Its Frame B structure provides improved heat dissipation compared to lower-rated models, allowing reliable performance inside compact industrial control cabinets.
