Brand:Yokogawa Electric Item No.:SR1B-045N-1KC Product Origin:Japan Product Dimensions:130 x 125.5 x 32.8 mm Product Weight:0.3 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Yokogawa SR1B-045N-1KC Digital Output Module is a compact and reliable solution for industrial digital control. It enables precise, high-speed switching for a variety of field devices while maintaining system integrity. Its diagnostic capabilities and SR series compatibility make it a trusted component for distributed control systems and automated process applications.
Technical Specifications
Specification
Details
Output Type
Digital
Compatible Systems
Yokogawa SR Series DCS
Dimensions
130 mm × 125.5 mm × 32.8 mm
Weight
0.3 kg / 0.66 lb
Operating Temperature
0°C to 55°C
Mounting Type
DIN-rail or Rack Mount
Diagnostics
Open/short detection, load monitoring
Power Supply
SR Series Bus Powered
Cooling Method
Passive
Applications
The Yokogawa SR1B-045N-1KC Digital Output Module is designed for precise control of actuators, relays, and other digital field devices in industrial automation systems. Common applications include process automation, manufacturing lines, water treatment, and power generation where reliable switching and real-time digital control are required.
Advantages
High-Speed Switching: Provides rapid response for digital output signals.
Compact and Space-Saving: Fits easily within standard control cabinets.
Reliable Performance: Industrial-grade construction ensures continuous operation.
Integrated Diagnostics: Detects output faults and ensures signal integrity.
Seamless System Integration: Compatible with Yokogawa SR series bus and controllers.
Easy Installation: Standardized connectors for plug-and-play deployment.
Technical FAQs
What type of outputs does the module support?
Supports standard digital outputs for driving relays, solenoids, and other actuators.
Is it hot-swappable?
No, module replacement requires power-down to maintain safe operation.
What is the response time for output signals?
Typical switching response is under 2 milliseconds.
Does it include fault detection?
Yes, the module provides diagnostics for open circuits, short circuits, and load errors.
What operating temperature range is supported?
Fully operational between 0°C and 55°C.
How is it mounted?
Standard DIN-rail or rack mounting depending on the system configuration.
Is the module compatible with legacy SR systems?
Yes, backward-compatible with previous SR series digital output modules.
Does it require an external power supply?
Powered through the SR series bus system; no additional supply needed.
Can it provide real-time status feedback?
Yes, the module communicates output status to the main SR series controller.
Is it suitable for high-vibration industrial environments?
Yes, designed to withstand typical industrial vibrations without performance degradation.
