Brand:Schneider PLC Item No.: TWDXCPMFK32 Product Origin:France Product Dimensions:110 × 66.8 × 50 mm Product Weight:0.3 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Schneider TWDXCPMFK32 EEPROM Memory Cartridge is a compact storage accessory developed for Twido programmable controllers. Featuring 32 KB of non-volatile EEPROM memory, it provides a secure method for backing up and transferring PLC application programs, helping engineers minimize downtime while simplifying controller replacement and system maintenance.
Designed for OEM machine builders, system integrators, and maintenance professionals, the TWDXCPMFK32 offers dependable program retention, straightforward installation, and seamless compatibility with Twido controllers. Whether protecting valuable application data or deploying identical programs across multiple machines, this memory cartridge delivers a practical and reliable solution for industrial automation environments.
Technical Specifications
Specification
Details
Manufacturer
Schneider Electric
Model
TWDXCPMFK32
Product Family
Twido
Module Type
EEPROM Memory Cartridge
Memory Type
EEPROM
Memory Capacity
32 KB
Storage Function
User Program Backup
Number of Stored Programs
1
Compatible Controllers
Twido Compact & Modular Controllers
Programming Software
TwidoSuite / TwidoSoft
Installation
Plug-in Cartridge
External Power Required
No
Mounting Position
Controller Memory Slot
Protection Rating
IP20 (Installed)
Operating Temperature
0°C to +55°C
Storage Temperature
-25°C to +70°C
Dimensions
Approx. 45 × 22 × 8 mm
Weight
Approx. 0.01 kg
Recommended Companion Models
Model
Product Name
Schneider TWDLMDA20DTK
Modular Base Controller
Schneider TWDLMDA40DUK
Modular Base Controller
Schneider TWDNOZ485T
RS485 Serial Communication Module
Schneider TWDXCPRTC
Real-Time Clock Cartridge
Frequently Selected Alternatives
Model
Product Name
Schneider TWDXCPMFK64
64 KB EEPROM Memory Cartridge
Schneider TWDXCPRTC
Real-Time Clock Cartridge
Schneider TWDNOZ232D
RS232 Serial Communication Module
Schneider TWDNCO1M
CANopen Bus Master Module
Where It Excels in Industrial Use
• PLC Program Backup and Recovery
The Schneider TWDXCPMFK32 is a 32 KB EEPROM memory cartridge designed for Twido programmable controllers. It provides a secure and removable storage medium for backing up PLC applications, enabling rapid recovery and simplified maintenance of industrial automation systems.
• Machine Commissioning and Deployment
The cartridge allows engineers to duplicate validated control programs across multiple Twido controllers, helping reduce commissioning time for OEM machinery and production equipment.
• Maintenance and System Replacement
Ideal for preventive maintenance and controller replacement projects, the TWDXCPMFK32 enables quick restoration of application programs without requiring a programming computer.
• Legacy Twido Automation Systems
Specifically developed for the Schneider Electric Twido PLC platform, the memory cartridge remains an essential accessory for maintaining existing automation installations and protecting valuable application data.
Key Strengths at a Glance
• 32 KB Non-Volatile EEPROM Storage
Provides reliable non-volatile memory capable of retaining user applications even when power is removed.
• Fast Program Backup and Restore
Supports rapid transfer of PLC applications between compatible controllers, minimizing equipment downtime during servicing or replacement.
• Simple Plug-In Installation
Installs directly into compatible Twido compact and modular controllers without requiring additional hardware or external power.
• Reliable Industrial Data Protection
EEPROM technology provides dependable long-term storage for automation programs, making it suitable for demanding industrial environments.
Technical FAQs
1. What is the Schneider TWDXCPMFK32?
The TWDXCPMFK32 is a 32 KB EEPROM memory cartridge designed for Schneider Electric Twido programmable controllers.
2. What is the primary purpose of this memory cartridge?
It is used to back up, store, and transfer PLC application programs between compatible Twido controllers.
3. What type of memory does the TWDXCPMFK32 use?
The cartridge utilizes non-volatile EEPROM memory for secure application storage.
4. What is the available storage capacity?
The memory cartridge provides 32 KB of accessible EEPROM storage.
5. Which PLC family is compatible with the TWDXCPMFK32?
It is compatible with Schneider Electric Twido compact and modular programmable controllers that support memory cartridges.
6. Can more than one application be stored on the cartridge?
No. One user application program is stored on a single TWDXCPMFK32 memory cartridge.
7. Does the cartridge expand the PLC program memory?
For most Twido controllers, the TWDXCPMFK32 is intended primarily for application backup rather than memory expansion.
8. Is external power required for the memory cartridge?
No. The cartridge is powered through the compatible Twido controller when installed.
9. Which programming software supports the TWDXCPMFK32?
The cartridge is used together with Schneider Electric TwidoSuite (formerly TwidoSoft) programming software.
10. Is the TWDXCPMFK32 suitable for industrial maintenance applications?
Yes. It is widely used for controller replacement, application backup, preventive maintenance, and machine duplication within existing Twido automation systems.
