Product Overview
The Schneider VW3M5121R50 Power Cable Module is a professional servo motor connection solution engineered for demanding industrial automation applications. Designed for BCH servo motors without a holding brake, it provides a reliable electrical connection between the motor and a compatible Lexium 23 Plus servo drive, helping maintain stable motion performance under continuous operating conditions.
Featuring a factory-assembled construction, a durable metal military-style connector, and industrial-grade cable materials, the VW3M5121R50 simplifies installation while enhancing long-term system reliability. It is an excellent choice for OEM machine builders, automation integrators, and maintenance professionals who require dependable power connectivity for precision motion systems.
Technical Specifications
| Specification | Details |
|---|
| Manufacturer | Schneider Electric |
| Model | VW3M5121R50 |
| Product Type | Power Cable Module |
| Accessory Category | Connection Accessory |
| Compatible Series | Lexium 23 Plus |
| Compatible Servo Motor | BCH Series (Without Holding Brake) |
| Cable Length | 5 m |
| Cable Composition | 4 × 1.3 mm² |
| Motor Side Connection | Metal Military-Type Connector |
| Drive Side Connection | Free Flying Leads |
| Installation | Between Servo Motor and Servo Drive |
| Dimensions | Cable Length: 5000 mm |
| Weight | 0.350 kg |
Recommended Companion Models
| Model | Product Name |
|---|
| VW3M5121R30 | Servo Motor Power Cable |
| VW3M5121R100 | Servo Motor Power Cable |
| VW3M5121 | Servo Motor Connector |
| LXM23PU15M3X | Servo Drive |
Frequently Selected Alternatives
| Model | Product Name |
|---|
| VW3M5122R50 | Servo Motor Power Cable |
| VW3M5131R50 | Servo Motor Power Cable |
| VW3M4112 | CN1 I/O Connector Module |
| BCH1302M | AC Servo Motor |
Technical FAQs
1. What is the primary purpose of the VW3M5121R50?
The VW3M5121R50 is a dedicated servo motor power cable used to connect compatible BCH servo motors without a holding brake to Schneider Electric Lexium 23 Plus servo drives for reliable power transmission.
2. Which Schneider Electric product range is compatible with this cable?
It is designed for the Lexium 23 Plus motion control platform and supports compatible BCH series servo motors without a holding brake.
3. What type of connector is installed on the motor side?
The motor side is equipped with a robust metal military-style connector that provides secure locking and dependable electrical contact during continuous industrial operation.
4. What conductor configuration does the cable use?
The cable features a 4 × 1.3 mm² conductor configuration, providing efficient power delivery for compatible servo motor applications.
5. Is this cable intended for communication or encoder signals?
No. The VW3M5121R50 is exclusively a servo motor power cable and is not designed for encoder feedback or industrial communication networks.
6. Can this cable be used with BCH motors equipped with a holding brake?
No. This model is specifically designed for BCH servo motors without a holding brake. Applications requiring brake wiring should use the corresponding brake-compatible cable.
7. Does the drive side include a factory-installed connector?
No. The drive side is supplied with free flying leads, allowing flexible wiring inside the control cabinet.
8. What installation benefits does the preassembled design provide?
The factory-assembled construction minimizes wiring time, reduces installation errors, and improves commissioning efficiency.
9. Is the cable suitable for continuous industrial operation?
Yes. It is designed for demanding industrial automation environments where reliable servo motor power transmission is essential.
10. Why is it recommended to use an original Schneider Electric cable?
Original Schneider Electric accessories ensure mechanical compatibility, stable electrical performance, and dependable operation with supported Lexium motion control systems.
